PRO-No-girder Large Roof Span Roll Forming Machine

PRO-No-girder Large Roof Span Roll Forming Machine thumbnail-1
PRO-No-girder Large Roof Span Roll Forming Machine photo-1
US$ 30,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Tile Forming Machine
Tile Type:
Steel
Contact Supplier Request Quote Chat Now
Yingkou Professional Roll Forming Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Tile Forming Machine
Tile Type Steel
Use Roof
Production Capacity 61%
Place of Origin Liaoning, China
Brand Name PRO
Model Number PRO-1000-610
Power(W) 17900
Voltage 380v
Dimension(L*W*H) 11650mm*2230mm*2400mm
Weight 12t
Certification CE
Warranty 13 months after B/L date, 1 year
After-sales Service Provided Engineers available to service machinery overseas

PRO-No-girder large span roll forming machine

duct list

Model

Feeding

 width

(mm)

Effective

width

(mm)

Depth of

 groove

(mm)

utilization

 ratio

Largest

span (m)

600-300

600

300

100

50%

30

600-305

600

305

109

50.8%

28

914-400

914

400

210

43.7%

40

914-610

914

610

203

66.7%

38

914-650

914

650

181

71.1%

26

914-700

914

700

123

76.5%

22

914-750

914

750

180

82%

14

1000-610

1000

610

243

61%

42

1000-680

1000

680

223

68%

38

1000-700

1000

700

175

70%

30

1000-750

1000

750

138

75%

24

1000-800

1000

800

114

80%

18

1200-800

1200

800

265

67%

40

1220-800

1220

800

355

66%

42

1250-800

1250

800

320

64%

45

2.main parameters

Size: 11650mm × 2230mm × 2400mm
Total Weight: About 15000KG
MainMotorPower:18.9KW
Bending power: 3.0kw+1.1x2kw
Sewing power: 2.2kw
 Cutting  power: 4.0kw
 Forming power: 7.5kw
Working Speed:  Straight sheet: 15m/min
                         Arch sheet: 13m/min
                         Sewing: 16m/min
Feeding Width: 1000mm
Effective Width: 610mm
Step of rollers: 14 steps
Controlling system: PLC (Ormon)
Material of cutting blade: Cr12 moV
Sheet operating factor: 61%
Thickness of the coil: 0.6-1.5mm
Material of roller shaft: 45# steel, galvanized
Material of rollers: 45# steel, quenched with hard chrome
Type of cutting: Roll-formed and length-set cutting
Electric Standard : 380V / 50 HZ / 3 PHASE
The depth of the groove:243mm
Proper span: ≤39m
Ship Container: 40’HQ x 1

ducts pictures

PRO-No-girder large roof span roll forming machinePRO-No-girder large roof span roll forming machinePRO-No-girder large roof span roll forming machinePRO-No-girder large roof span roll forming machine
