Specifications
This tester is a powerful indispensable tool for repair technicians to diagnose common rail engine ECU, fuel system and rail senRA-1101 Rail Pressure Tester is designed to test Bosch rail pressure sensor for common rail diesel engines. RA-1101 can be used to monitor engine rail pressure and diagnose common rail diesel engine faults with no interference to engine ECU during engine running by the site of a fault vehicle. RA-1101 can test also rail pressure for a common rail fuel system on a fuel pump test bench independently. RA-1101 is able to detect the DC +5V power supply for the sensor and switch automatically the power supply source, for which the default is an external ECU +5V power supply and the alternative is the internal +5V power supply of the tester.
This tester is a powerful indispensable tool for repair technicians to diagnose common rail engine ECU, fuel system and rail sensor.
Design Features
l Compact and easy to use
l Able to test Bosch rail pressure sensors in 3 scales, 0-1500bar, 0-1800bar, and 0-2000bar
l Able to measure fuel rail pressure in real-time and diagnose common rail diesel engine faults on site of faulty vehicles
l Able to monitor rail pressure sensor without affecting diesel engine ECU rail pressure signal
l Able to detect the source of +5V power supply for the rail pressure sensor, switch automatically to the power supply available and display the power supply source on its screen
l Over-pressure warning
l Battery low indication
l A full set of accessories, harness, battery
The following common rail engine faults can be determined based on the test results by the RA-1101 Rail Pressure Tester
l Whether the ECU +5V power supply is normal or not
l Whether ECU rail pressure signal circuit is normal or not
l Whether rail pressure sensor has fault or not
l No sufficient rail pressure during the engine starts is an indication of faults on the engine fuel system, low pressure circuit or high pressure pump
