Standard hot dipped galvanized Gabion baskets with high quality
1.Hexagonal Wire Netting Gabions are wire containers made of hexagonal wire netting. Wire diameter varies with
the hexagonal nettings. For hexagonal wire netting with no pvc coating, the wire diameter ranges from 2.0mm to
4.0mm. For those PVC coated hexagonal wire netting, the outside diameter ranges from 3.0mm to 4.0mm.
Gabions sizes: 2m x 1m x 1m, 3m x 1m x 1m, 4m x 1m x 1m, 2m x 1m x 0.5m, 4m x 1m x 0.5m. Custom orders
available.
Finish can be hot-dipped galvanized, galvanized aluminum alloy or PVC coated, etc
2.
Hexagonal Wire Netting Gabions | |||
Opening |
Wire Diameter(Metal Wire) |
Wire Diameter (PVC Coate)/ |
Strands |
60X80 |
f2.0-2.8 |
f2.0/3.0-2.5/3.5 |
3 |
80X100 |
f2.0-3.2 |
f2.0/3.0-2.8/3.8 |
3 |
80X120 |
f2.0-3.2 |
f2.0/3.0-2.8/3.8 |
3 |
100X120 |
f2.0-3.4 |
f2.0/3.0-2.8/3.8 |
3 |
100X150 |
f2.0-3.4 |
f2.0/3.0-2.8/3.8 |
3 |
120X150 |
f2.0-4.0 |
f2.0/3.0-3.0/4.0 |
3 |
3.Weaving : Straight twist , reverse twist, double twist, the first series after plating , the first series after plating.
5. application:
(1)Control and guide of water or flood
(2)Flood bank or guiding bank
(3)Preventing of rock breaking
(4)Water and soil protection
(5)Bridge protection
(6)Strengthening structure of soil
(7)Protection engineering of seaside area.
6.Packing: Flat bundle, binding with steel strape or strands
The standard size of gabion box more welcome by foreign market as below:
Hot dipped galvanized, Opening:80*100mm, wire diameter:2.7mm, edge wire diameter:3.4mm,tie wire 2.2mm, gabion sizes:2m x 1m x 1m.
Gabion mesh box factory
galvanized gabion mesh box
PVC coated gabion mesh box
Gabion mesh box machine
gabion baskets uesd
Gabion baskets loading
Our advantages:
a.We are the manufacturer, not trading company, price will be more competitive
b.We have produced strickly in according to the customers’ request.
c. We adhere to the operational theme of “good Quality , high Credibility and best Service".
We can promise : We will give you the cost price for the first cooperation
