PVC sheet is a high polymer waterproof material, which is processed by using the Polyvinyl Chloride Resin (PVC) as the base material, mixing with plasticizers, UV absorbers and other additives.
Advantages:
1. High tension, perfect elongation to resist the stretching or cracking of the foot layer.
2. Perfect jointing, It can be fused with base as a whole after heating the jointing by hot wind.
3. High permeability, chilling material and moisture can be expelled easily.
3. High aging resistance, UV resistance, corrosion resistance and erosion resistance.
4. Good cold flexibility and heat resistance
Scope of Application
1 Large-scale underground structures.
2 Surface of concrete slabs for planting.
3 For Roads, Rails, Subway tunnels projects.
4 For reservoirs, canals, dams and other water conservancy projects.
5 For air defense, military facilities waterproof projects.
Product Performance
1. Long life, anti-aging, roofing materials can be used more than 20 years, underground up to 50 years.
2. Tensile strength, high elongation, heat treatment of small size changes.
3. A good l ow temperature flexibility and adapt to environmental temperature change is good.
4. Resistance to root penetration, and can be made into green roofs.
5. Anti-perforation is good.
6. Convenient for construction, welding, solid and reliable and environmentally friendly non-polluting.
7. Resistance to chemical corrosion resistance, applicable to special occasions.
8. Has good plasticity, corner detail treatment convenient.
9. Easy maintenance and low cost.
Operation points
Generally, heat the jointing with the hot air or electric heating with hot air or welding by electricity. Waterproof construction of complex parts can be used matching PVC special accessories.
Technical Capacity Index (Ref to Chinese Standard GB12952-91)
Guangdong Province Contruction Products Inspection Center | |||
Test Report | |||
Sample name:DY-PVC Roofing Waterproof Membrane |
Ref No:DY2011-01-033 |
||
Specifation/modle: DY-PVC(N.I) |
Sample No:011-01-00033 |
||
Ref Standards:GB12952-2003 |
Sample quanity: 2.05 sqm |
||
| |||
No. |
Test Item |
Standard value |
Measured value |
| 1 | Tensile strength, Mpa |
≥8.0 |
8.37 |
| 2 | Elongation,% |
≥200 |
236 |
| 3 | Anti-penetration resistance |
.3Mpa in 2 h, No leakage | No Leakage |
| 4 | Cold flexible |
.-20°C,No cracking |
No cracks |
| 5 | Adhesivity in shear conditon, N/mm |
≥3.0 |
3.27 |
Conclusion |
All test are qualited based on the Ref Standards: GB12952-2003 's conventional items and instruction . |
||
Remarks |
|||
