Help CenterPortable Ultrasonic Flow Meter
US$ 500 - 3,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
CEPAI
Model Number:
CPS-2000H
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Vortex Flow Meter With Temperature and Pressure CompensationUS$ 500 - 500MOQ: 2 Sets -
Digital Water Flow MeterUS$ 500 - 3,000MOQ: 1 Set
-
Separate Electromagnetic Flow MeterUS$ 500 - 3,000MOQ: 1 Set
-
Metal Tube RotameterUS$ 500 - 500MOQ: 2 Sets
-
Turbine Liquid Flow TransmitterUS$ 500 - 500MOQ: 2 Sets
Place of Origin
Jiangsu, China
Brand Name
CEPAI
Model Number
CPS-2000H
Product Description
CPS-2000H Feature:
1. Several types transducer for selection, measuring pipe size from
DN15mm to DN6000mm
2. Linearity: better than 0.5%, Repeatability: better than 0.2%, Accuracy:
better than ±1%
3. Non-intrusive, clamp-on transducer, no pressure drop, no pipe
disturbance.
4. Chinese & English display, easy to operate.
5. Built-in rechargeable Ni-MH rechargeable battery, provide over 20
hours of continuous operation
6. Built-in mini thermal printer with instant and timing print function
7. Uplink over 20 measuring data to computer or internet
General Specifications
| Items | Specifications |
| Main unit | 2 line x 20 character LCD with backlight Working temperature: -25--60°C |
| Mini thermal printer with 24 line character output | |
| 4x4+2 pushbutton keypad | |
| RS-485 interface for networking | |
| Ultrasonic Transducer options |
TS-1: small size transducer (magnetic) for pipe size: DN15-100mm, liquid temperature ≤110°C |
| TM-1:medium size transducer (magnetic) for pipe size:DN50-1000mm, liquid temperature ≤110°C Ultrasonic Transducer options | |
| TL-1: Large size transducer (magnetic) for pipe size: DN300-6000mm, liquid temperature ≤110°C | |
| Temperature Transducer |
Three wire pt100 platinic resistance, measuring range :-50 -----180°C measuring accuracy:100°C, 0.8°C , the temperature difference ≤0.1°C |
| Liquid types | Water, sea water, industrial sewage, acid and alkali liquid, various oils etc. liquid which can transmit sound wave. |
| Flow velocity range |
0- ±30m/s |
| Accuracy | Better than ±1% |
| Power Supply | Built-in rechargeable Ni-MH battery (for 20 hours operation) or AC 220V |
| Power Consumption |
1.5W |
| Charging | Intelligent charging with AC 220V; After charging sufficiently, it automatically stop and display green light |
| Weight | Net weight: 2.5kg (main unit) |
| Remarks | With a high strength carrying case suitable for normal and harsh environment |
