Specifications
Great Wall High Pressure Mill1.Simple operation
2.High productivity
3.Low power consumption
4.Long service life top quality
"Great Wall Make Great Machine"
Different Colors&Packages are available
Other HOTEST MODELS For View
ISO9001:2008 Approved,For test report details,pls contact "GreatWall"
Great Wall YGM High Pressure Mill
Usage and Application
It is used to grind materials in the fields of construction, mining, metallurgy and chemical industry. The materials should be non-flammable and non-explosive. Examples of the materials are: quartz, feldspar, barite, fluorite, dolomite, garnet, carborundum, bauxite, zircon, marble, calcite, iron ore, rock phosphate, coal, ceram, slag and so on (400 kinds of materials). The materials should have the hardness less than 9.3 in Moh's scale and humidity less than 6 percent. The granularity of the end products can be changed from 30 to 425 meshes.
Working Feature
It has the same working principle as Raymond Mill, but its grinding device is fixed with 1000 - 1500 kg pressure spring. When the machine works, the grinding roller, under the action of high pressure spring and centrifugal force, rolls close up to grinding ring, its rolling pressure is 1.2 times higher than that of Raymond mill given an identical condition and its output may increase 20% to 30%; When the grinding roller and grinding ring reach a certain degree of abrasion by adjusting the length of high-pressure spring to keep the constant grinding pressure between grinding roller and grinding ring, stable output and fineness are guaranteed.
Main Specifications
Model |
Grinding Roller |
Grinding Ring |
Feeding |
Output |
Capacity |
Motor |
Overall |
|||
Numbers |
Diameter |
Height |
Outside |
Height |
||||||
YGM65 |
3 |
210 |
150 |
726 |
150 |
<15 |
0.613-0.033 |
0.3-2.0 |
28.2 |
4480×3100×3970 |
YGM75 |
3 |
260 |
150 |
865 |
150 |
<15 |
0.613-0.033 |
0.4-3.1 |
35.7 |
5000×4100×4850 |
YGM85 |
3 |
270 |
140 |
907 |
140 |
<20 |
0.613-0.033 |
0.5-4.0 |
42.7 |
5150×5000×5200 |
YGM95 |
4 |
310 |
170 |
1050 |
170 |
<25 |
0.613-0.033 |
1.1-5.6 |
72.5 |
7550×7400×8100 |
YGM130 |
5 |
410 |
210 |
1400 |
210 |
<30 |
0.613-0.033 |
2.2-9.5 |
157.5 |
8510×8000×9645 |
YGM160 |
6 |
440 |
270 |
1740 |
270 |
<35 |
0.613-0.033 |
8-22 |
253 |
12550×5700×8355 |
Services:
1.Pre-sales Service
Offering comprehensive technical and business consultation services;
Proposing th e most suitable scheme and equipment for our clients;
Designing and fabricating targeted products according to the special requirements of clients;
Training periodically high qualified service technician.
2.After-sales Service
Highly inspecting equipments in every working procedure, quality comes first;
Fast & Safe Delivery;
Assisting our clients for foundation construction of equipments;
Dispatching engineers to install and debug equipments;
Training the first-line operators on site;
Regularly visit clients to solve production problems;
Providing life-long maintenance service;
Providing technical exchanging;
About Us:
With more than twenty years' history, Zhengzhou Great Wall Heavy Industry Machinery Co.,Ltd. is a manufacture which specialized in R&D, manufacturing and selling big and middle size heavy industry machinery. Since establishment, we make a good image in the market with scientific management, qualified products and perfect service.
Our main products are crushers, grinding mills, other equipments for crushing plant and grinding plant, as well as building construction equipments. They are widely used in mining, building material, metallurgy, chemical, traffic, reservoir and so on. Our products are not only sold well in more than twenty provinces and cities in China, but also in tens of countries and regions in Eastern Europe, Middle East, Asia, Africa, North America, South America, and Oceania.
Now we have domestic top ranking production equipments and precise testing instrument, each process of products is strictly inspected to guarantee the products to achieving high ex-factory standard. Besides, we cooperate with many famous universities and scientific research institutions, so that can make technical warrantee for the products in it's developing, updating and improving.
"persons of ability guarantee the quality". Our company takes in persons of ability and gives training to the staffs annually to their quality and skill to meet the development of the company.
With the right of importing and exporting, the company owns an international trading department which is specialized in sales and exports, we provide the best service to the foreign clients.
During the past years, we stick to "honest, truth-seeking, innovation and hard working". To keep "Great Wall" brand, we will improve ourselves and try our best to make perfect products and the best service.
Do not hesitate send us inquiry for more details about the Great Wall YGM High Pressure Mill.
