GBDE Type Two Layer Four Lines PE Plastic T-shirt Bag Making Machine

GBDE Type Two Layer Four Lines PE Plastic T-shirt Bag Making Machine thumbnail-1
GBDE Type Two Layer Four Lines PE Plastic T-shirt Bag Making Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Machine Type:
Bag Forming Machine
Bag Type:
Shopping Bag
Contact Supplier Request Quote Chat Now
Wenzhou Duke Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Machine Type Bag Forming Machine
Bag Type Shopping Bag
Material Plastic
Computerized Yes
Place of Origin Zhejiang, China
Brand Name Duke
Model Number GBDE-700
Voltage 220V
Power(W) 1.5KW
Dimension(L*W*H) 3.2X1.1X1.6M
Weight 1.5T
Certification CE
Warranty One year
After-sales Service Provided Engineers available to service machinery overseas

GBDE Type Two Layer Four Lines PE Plastic T-shirt Bag Making Machine Main Technical Variables:

Descriptions:


This Plastic T-shirt Bag Making Machine is suitable for producing HDPE and LDPE plastic . It adopts the servomotor discharge the in high speed and photocell to track the cutting, punch the "U"shape bag in one tine. And with such features, such as casy operation, high effciencyand high finished products.



  Technical Parameters:


Type

GBD-E600

GBD-E700

Sealing and Cutting Width

150-260mm

180-310mm

Sealing and Cutting Length

300-650mm

300-650mm

Sealing and Cutting Thickness

0.015-0.04mm

0.015-0.04mm

Bag Making Speed

(5-100)×4pcs/min

(5-100)×4pcs/min

Motor Power

1.5kw

1.5kw

Machine Weight

≈700kg

≈700kg

Overall Dimensions(L×W×H)mm

3200×1100×1600mm

5200×1300×1800mm

Air Compress

5kg/Cm2

5kg/Cm2



 Finished T-shirt Bag Samples:

GBDE Type Two Layer Four Lines PE Plastic T-shirt Bag Making Machine

GBDE Type Two Layer Four Lines PE Plastic T-shirt Bag Making Machine



 Optional Deivce:

GBDE Type Two Layer Four Lines PE Plastic T-shirt Bag Making Machine

 Details Photos:



Plastic Bag Making Machine Feeding Parts: Four Lines

GBDE Type Two Layer Four Lines PE Plastic T-shirt Bag Making Machine



Sealing And Cutting Knife : Hot Sealing And Cold Cutting

 GBDE Type Two Layer Four Lines PE Plastic T-shirt Bag Making Machine



 GBDE Type Two Layer Four Lines PE Plastic T-shirt Bag Making Machine



GBDE Type Two Layer Four Lines PE Plastic T-shirt Bag Making Machine



GBDE Type Two Layer Four Lines PE Plastic T-shirt Bag Making Machine



Punching Unit:T-shirt Bag Automatic Punching

GBDE Type Two Layer Four Lines PE Plastic T-shirt Bag Making Machine



Conveyor Belt For Finished Bags:

GBDE Type Two Layer Four Lines PE Plastic T-shirt Bag Making Machine



GBDE Type Two Layer Four Lines PE Plastic T-shirt Bag Making Machine



Machine Packing And Shipping :Wooden Case More Safe



GBDE Type Two Layer Four Lines PE Plastic T-shirt Bag Making Machine



GBDE Type Two Layer Four Lines PE Plastic T-shirt Bag Making Machine
