Multifunctional Sugar Cube Machine|Cube Sugar Machine|Sugar Cube Making Machine
Hot Sale Cube Sugar Production Line
1. Sugar Crusher
Model |
HQL-4-SC |
Production capacity |
50-100 kg / h |
Feed size |
<5mm |
Crushing fineness (mesh) |
12-150 |
Motor Power |
3Kw |
Dimensions (L*W*H) |
670*650*1200 |
Weight |
80Kg |
Cube bulk |
0.92 |
2.Cube Sugar Machine
This equipment is a kind of automatic send sugar, automatic forming technology, continuous briquetting machine,
which is mainly used for pressure square shape, and other various shapes.This equipment is mainly used for powder
or particles of water, such as sugar (sugar, red sugar) .
Model |
HQL-4-CS(PLC control) |
Production capacity |
44000 Granules/H |
Motor power |
3Kw |
Voltage |
380 V, 50 Hz |
Rotary speed |
960 Loop/Min |
Dimension: (L×W×H) |
1800×750×1750mm |
Cubage |
2.8 cube meters |
Gross Weight |
600KG |
3.Mixed Spiral Feed Machine:
Model |
HQL-4-MS |
Efficiency |
1-3M3/H,infinite speed variation |
Motor power |
3.85KW |
Discharge port from the ground |
1700mm |
Gross weight |
140KG |
Cubage |
1.81 cube meters |
Outline Air Consumption(L×W×H,MM) |
500*500*1650mm |
Outline Air Consumption(L×W×H,MM) |
520*520*900mm |
Function: mixing, automatic feeding | |
4.The Infrared Drying Oven:
This equipment structure compact, aesthetically pleasing, oven wall and conveying chain adopt 1 cr18ni9ti
or high-quality stainless steel SUS304.Using far-infrared radiation heating, electric heating tube inside
the oven insulation layer using superfine glass wool or aluminum silicate as insulation materials, heat
preservation performance is good, it is an ideal equipment for continuous drying of sugar.
Model :HQL-4-DO
Efficiency:0-10M/M/min
Outline Air Consumption(L×W×H,MM):2000*470*1400
Gross weight:140KG*5
Cubage:4.5cube meter
Power:AC380V50HZ 2.4KW
5.Cooler Machine:
Model:HQL-4-CM
Function:0-10M/M/min
Efficiency:0-10M/M/min
Dimensions:1900*700*700MM
Gross weight:60KG
Cubage:0.93
6.Semi-automatic Vacuum Filling Machine
Model:HQL-4-VF
Efficiency:Infinite speed variation
Suction: 3N Sucking disc:2
Outline Air Consumption(L×W×H,MM):500*750*1350MM
Gross weight:320KG
Cubage:0.506
Quantity:1sets
