OLG-480WZ Water Cooling Screw Air Compressor, Air Compressor

Name: OLG-480WZ Water Cooling Screw Air Compressor, Air Compressor
Brand: Acecare
SKU: 137814477

US$ 5,000 - 15,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Screw

Configuration:

Stationary

Shenyang Acecare Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Screw

Configuration Stationary

Power Source AC Power

Lubrication Style Lubricated

Mute Yes

Place of Origin Liaoning, China

Brand Name Acecare

Model Number OLG-480WZ

Voltage 10000/6000

Dimension(L*W*H) 3875*2280*2226mm

Weight 5700KG

OLG-480WZ Water Cooling Screw Air Compressor

1.noise isolation design for the whole machine

2.high-quality mainframe

3.efficient ,energy-saing and quite firm motor

NO.	project		unt	parameters
1	air displacement/pressure		(m3/min)/ MPa	57/0.7-0.75
				55.6/0.8-0.85
				50.2/1.0-1.05
				41.9/1.2-1.25
2	ambient temperature		°C	-5~+45
3	cooling model			water cooling
4	exhaust air temperature		°C	≤ambient temperature +5
5	lubricant oil		L	205
6	drive model			dirctly
7	volume adjustment model			ON/OFF automatic adjustment
8	gas oil content		ppm	≤3
9	noise		dB(A)	79±2
10	brand of lubricant oil			ORIENT oil
11	safety valve work pressure		MPa	specified work pressure x1.1
12	motor	power	KW/HP	315/420
		speed	rpm	1485
		drive model		direct step-down start
		voltage/rate	V/Hz	10000,6000/50
		levels of protection/insulation rating		IP23,F stage
13	size(L×W×H)		mm	3875×2280×2226
14	Net wight		kg	5700
15	output interface		in	DN125/G5″
