Specifications
TDS623 industrial rotary dryer1.Drying capacity:1-3m3/h
2.Diameter of drum:2.2m
3.Length:1.5m
4.Motor power:4kw
Industrial rotary dryer TDS623 small rotary dryer/ sand dryer
1. Introduction of TDS623 industrial rotary dryer
Sand Rotary Dryer is suitable to dry metallic and nonmetallic mineral, clay in cement industry and coal in coal mine, etc. Rotary dryer can be widely used to dry variousmaterials, and it is simple to be operated.
2. Features of TDS623 industrial rotary dryer
1).Three cylinder dryer use telescope-feed structure, dry the material quickly
2).Simple design, self-insulation, improve the heat efficiency to exceed 80%
3).Structure delicate, stable operation
4).gooddryingperformance, coal consumption <8kg when drying 1t material
5).The fuel can be coal, oil, natural gas etc, dry mass, granule and powder material
6).Reduce land area for 50% compared to single drum rotary dryer, so construction investment is saved 50%power consumption saved 60%
3. Parameters of TDS623 industrial rotary dryer
Three Pass Dryer |
TDS623, 1 set |
Drying capacity |
1-3 m3/h |
Diameter of drum |
2200mm |
Length |
1500mm |
Motor power |
4kw |
Reducer model |
XWD-5 |
Speed of drum rotation |
4-10 r/min |
Moisture of end products |
0.1%-0.8% |
Max. temperature inside |
700-750℃ |
Outlet temperature |
30-60℃ |
Hot-blast Stove dimensions |
1.55m×1.3m×2.18m |
Furnace door |
450*550 mm |
Quicksand tube |
φ165×1600 mm |
Coal consumption |
7-10 kg/ per ton sand |
Comparative advantage
