Concrete recycle machine for concrete mixer truck
1, Introductions of Concrete recycle machine TF-920
Spiral concrete stone separator, screw sand washer, is one of sand washer, which mixes the dinas by the spiral
device, so that make soil in the dinas mingle with water, then expel from the outlet of the equipment. The same
time, the dinas is selected stepwise under the action of helical gear. So the cleaning of dinas come true.
2, Application of Concrete recycle machine TF-920
Spiral sand washing machine is especially suitable for the production of abrasive, fire-proof material, cement, quartz sand steel shot slag powder copper ore iron ore, gold ore, concrete aggregate of
asphalt aggregate finely with many kinds of hard brittle materials such as crusher, which is a highly efficient,
energy-saving gravel sand making equipment, 50% energy saving than the traditional sand making machine.
Spiral sand washing applies to the choice of the fine-grained and coarsness material, which mainly used for highway, water and electricity, washing and classification
in the construction industries, as well as fine-grained and coarse-grained materials such as washing operation.
3, Parameters of Concrete recycle machine TF-920
Model |
LSY-920 |
2LSY-920 |
LSY-1120 |
2LSY-1120 |
Screw quantity |
1 |
2 |
1 |
2 |
Screw diameter(mm) |
920 |
920 |
1120 |
1120 |
Water channel(mm) |
7585 |
7580 |
9750 |
9750 |
Selected granularity(mm) |
10 |
10 |
10 |
10 |
Production capacity(t/h) |
100 |
200 |
175 |
350 |
Spiral speed(r/min) |
21 |
21 |
17 |
17 |
Motor power(kw) |
11 |
11*2 |
18.5 |
18.5*2 |
Water consumption(t/h) |
10-80 |
20-160 |
20-150 |
40-300 |
1, Delivery time: 15 days after receipt of your deposit.
2, Payment terms: 30% T/T in advance, the left is paid (by T/T) before delivery.
3, Package:
1),Wire cables are used for fastening the machine on the trailer or inside the container.
2),Cork wood are placed in front or behind the machine to protect it.
3),Plastic film is covered on the machine as a rain-roof.
4),Crane is used during the whole
