Specifications
Widely used construction hoistadvanced technology
safety and reliable operation
convenient maintenance and repair
Model: SC200/200
SC200/200 Construction Hoist is a new generation product which designed by the Institute of Building Mechanization of China Academy of Building Research. It own advanced technology, safety and reliable operation, convenient maintenance and repair. It the idealist transport equipment.
It has a variety of configurations: Frequency conversion system, Monitoring equipment, Layer stop protection device, GPS layer selecting system, Microcomputer wind speed device and so on, which are optional as required.
Main features of the widely used construction hoist
SC200/200 Construction Hoist adopted computer aided design. Comparing with traditional building hoists, it is attractive, light, easy to handle, secure, applicable, and popular. Depending on special needs of regular or irregular sections, the lifting capacity can reach up to 1~2 tons, and the running speed can reach 28~38m/min. Moreover, VVVF speed regulation and PLC enable 0~68 limitless speed, automatic layer selecting and leveling as required.
SC200/200 Construction Hoist is excellent in technical performance, more secure in operating mechanism, and more compact in structure
Technical parameters of the model: SC200/200
Name |
Unit |
SC200/200 |
|
Rating loading capacity
|
Kg |
2×2000 |
|
Passenger number
|
Person |
2×16 |
|
Rating rising rate
|
M/min |
36 |
|
Max. promoting height
|
m |
200 |
|
Motor power
|
KW |
2×3×11 |
|
Cage size
|
m |
3*1.5*2.5 |
|
650 mast section weight
|
Kg |
148 |
|
650 mast section length
|
mm |
650×650
×1508
|
|
Steeve rating rising weight
|
Kg |
200 |
We provide you reliable and fast package and variety kinds of transportation way to insure you get the goods in time and safely.
1.We have professional person on line to advise you the most suitable type of machie for according to your requirement.
2.Provide you comprehensive.easy-understanding and detail information and technical data about the machie you interested;solve your confusions or questions about the machine
3.Arrange the schedule if you pay a visit to our factory
4.Keep you in touch when the order is put on production.
5.Our engineer will guide the installation in your counrty if possible.
PLEASE CONTACT ME IF THERE'S ANY QUESTIONS,THANKS!
