2014 Double Row Angular Contact With Bearing 3316 C3 With Brass Cage

2014 Double Row Angular Contact With Bearing 3316 C3 With Brass Cage thumbnail-1
2014 Double Row Angular Contact With Bearing 3316 C3 With Brass Cage photo-1
US$ 30 - 30 MOQ: 10 Sets
Key Specifications
Get Latest Price
Brand Name:
CLUNT
Bore Size:
80,
Outside Diameter:
170,
Contact Supplier Request Quote Chat Now
Jinan Kelunte Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name CLUNT
Bore Size 80,
Outside Diameter 170,
Model Number 3316 C3
Precision Rating P0 P6 P5 P4 P2
Seals Type OPEN, Open type and sealed
Number of Row Double Row
Place of Origin Shandong, China





 2014 double row angular contact with bearing 3316 C3 with brass cage

 3316 A/C3 double row Angular contact ball bearings with greater axial internal clearance than normal.



Description of 3316 A/C3 double row Angular contact ball bearings

Inside diameter=80 mm

Outside diameter=170 mm

Width=68.3 mm

Weight=6.80 kg

Basic dynamic load rating=182 kN

Basic static load rating=156 kN

Fatigue load limit=6 kN

Reference speed=3400 rpm

Limiting speed=3600 rpm

escription:
CLUNT bearings
Original: Made in Austria CLUNT bearing company
CLUNT 3316C3 double row angular contact ball bearing
CLUNT 3316 C3 double row angular contact ball bearing
3316C3 CLUNT bearing, CLUNT 3316C3 bearing, CLUNT bearing 3316C3
3316 C3 CLUNT bearing, CLUNT 3316 C3 bearing, CLUNT bearing 3316 C3
CLUNT 3316C3 double row angular contact ball bearing

Principal dimension
d:
80 mm
D:
170 mm
H:
68.3 mm
Basic load ratings
C (dymaic):
182 KN
Co (static):
156 KN
Speed ratings
Reference speed:
3400 r/min
Limiting speed:
3600 r/min

Weight (mass):
6.8 kg

Cage material:
Steel cage



2014 double row angular contact with bearing 3316 C3 catalogue:



earing         No Bore Out Dia   Width Radius Limited Speed(RPM) Basico Loading(N)
d(mm) D(mm) B(mm) rsmin Grease Oil Dynamic Static
3000 3000-2RS 3000-2Z 10 26 12 0.3 18000 23000 5500 3200
3001 3001-2RS 3001-2Z 12 28 12 0.3 17000 22000 6100 3700
3002 3002-2RS 3002-2Z 15 32 13 0.3 14500 18000 8500 5400
3003 3003-2RS 3003-2Z 17 35 14 0.3 12500 16000 9000 6000
3004 3004-2RS 3004-2Z 20 42 16 0.6 11000 13000 14200 9600
3005 3005-2RS 3005-2Z 25 47 16 0.6 9500 12000 15200 11000
3006 3006-2RS 3006-2Z 30 55 19 1 8000 10000 20300 15500
3007 3007-2RS 3007-2Z 35 62 20 1 6500 8500 24200 20400
3008 3008-2RS 3008-2Z 40 68 21 1 6000 7800 24500 20800
3009 3009-2RS 3009-2Z 45 75 23 1 5600 6200 39300 36400
3010 3010-2RS 3010-2Z 50 80 23 1 5300 6600 42300 41900
3011 3011-2RS 3011-2Z 55 90 26 1.1 4800 5800 43700 44700
3012 3012-2RS 3012-2Z 60 95 26 1.1 4400 5000 47200 53400
3013 3013-2RS 3013-2Z 65 100 26 1.1 4000 4800 49500 59200
3014 3014-2RS 3014-2Z 70 110 30 1.1 3600 4400 54200 58900
3015 3015-2RS 3015-2Z 75 115 30 1.1 3400 4000 57700 66500
3016 3016-2RS 3016-2Z 80 125 34 1.1 3100 3800 63500 67800
3017 3017-2RS 3017-2Z 85 130 34 1.1 2900 3600 68300 77500
3018 3018-2RS 3018-2Z 90 140 37 1.5 2700 3300 69800 77300
3019 3019-2RS 3019-2Z 95 145 37 1.5 2600 3100 72400 82900
3020 3020-2RS 3020-2Z 100 150 37 1.5 2500 2800 74700 88200
3200 3200-2RS 3200-2Z 10 30 14.3 0.6 15000 20000 15000000 20000000
3201 3201-2RS 3201-2Z 12 32 15.9 0.6 14000 18000 14000000 18000000
3202 3202-2RS 3202-2Z 15 35 15.9 0.6 12000 16000 12000000 16000000
3203 3203-2RS 3203-2Z 17 40 17.5 0.6 11000 14000 11000000 14000000
3204 3204-2RS 3204-2Z 20 47 20.6 1 9000 12000 9000000 12000000
3205 3205-2RS 3205-2Z 25 52 20.6 1 8800 12000 8800000 12000000
3206 3206-2RS 3205-2Z 30 62 23.8 1 6500 8700 6500000 8700000
3207 3207-2RS 3207-2Z 35 72 27 1.1 5600 7500 5600000 7500000
3208 3208-2RS 3208-2Z 40 80 30.2 1.1 5000 6700 5000000 6700000
3209 3209-2RS 3209-2Z 45 85 30.2 1.1 4600 6100 4600000 6100000
3210 3210-2RS 3210-2Z 50 90 30.2 1.1 4300 5700 4300000 5700000
3211 3211-2RS 3211-2Z 55 100 33.3 1.5 3900 5100 3900000 5100000
3212 3212-2RS 3212-2Z 60 110 36.5 1.5 3500 4700 3500000 4700000
3213 3213-2RS 3213-2Z 65 120 38.1 1.5 3200 4300 3200000 4300000
3214 3214-2RS 3214-2Z 70 125 39.7 1.5 3100 4100 3100000 4100000
3215 3215-2RS 3215-2Z 75 130 41.3 1.5 2900 3900 2900000 3900000
3216 3216-2RS 3216-2Z 80 140 44.4 2 2700 3600 2700000 3600000
3302 3302-2RS 3302-2Z 15 42 19 1 10000 15000 16000 9000
3303 3303-2RS 3303-2Z 17 47 22.2 1 9400 13000 20400 12100
3304 3304-2RS 3304-2Z 20 52 22.2 1.1 8200 11000 20600 12700
3305 3305-2RS 3305-2Z 25 62 25.4 1.1 6800 9100 30500 20500
3306 3306-2RS 3306-2Z 30 72 30.2 1.1 5800 7800 39500 27500
3307 3307-2RS 3307-2Z 35 80 34.9 1.5 5200 7000 49500 35000
3308 3308-2RS 3308-2Z 40 90 36.5 1.5 4600 6100 60500 44000
3309 3309-2RS 3309-2Z 45 100 39.7 1.5 4100 5500 72500 54000
3310 3310-2RS 3310-2Z 50 110 44.4 2 3600 4800 85500 64500
3311 3311-2RS 3311-2Z 55 120 49.2 2 3400 4500 106000 82000
3312 3312-2RS 3312-2Z 60 130 54 2.1 3100 4200 122000 95500
3313 3313-2RS 3313-2Z 65 140 58.7 2.1 2900 3900 138000 109000
3314 3314-2RS 3314-2Z 70 150 63.5 2.1 2700 3600 155000 125000
3315 3315-2RS 3315-2Z 75 160 68.3 2.1 2500 3300 168000 141000
3316 3316-2RS 3316-2Z 80 170 68.3 2.1 2400 3100 176000 167000
3317 3317-2RS 3317-2Z 85 180 73 3 2200 3000 2200000 3000000
3318 3318-2RS 3318-2Z 90 190 73 3 2100 2800 2100000 2800000
3319 3319-2RS 3319-2Z 95 200 77.8 3 2000 2600 2000000 2600000
3320 3320-2RS 3320-2Z 100 215 82.6 3 1900 2500 1900000 2500000



CLUNT factory


Jinan Kelunte Bearing Co., Ltd. is a professional bearing manufacturer and is engaged in the imported bearings.
Our company is engaged in the imported bearings,company's main imported Roller Bearing,Ball Bearing,deep groove ball bearings,taper roller bearings,angular contact ball bearings,Pillow Block Bearing,Ceramic Bearing,cylindrical roller bearing, spherical roller bearing .

2014 double row angular contact with bearing 3316 C3 with brass cage2014 double row angular contact with bearing 3316 C3 with brass cage



Packaging & Shipping

2014 double row angular contact with bearing 3316 C3 with brass cage

1. Neutral Package: Plastic Tube + Carton + Pallet

2. Commercial Package: single CLUNT Box + Carton + Pallet

2014 double row angular contact with bearing 3316 C3 with brass cage

1. Payment:

   1) TT, 30% deposit , 70% before shippment.
   2) L/C at sight. (high bank charge, not suggest , but acceptable )
   3) 100% Western Union in advance. (specially for air shipment or small amount)

2. Delivery:

   1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient )

   2) Between 45 - 200 KGS, we will send by  air transport. ( Fastest and safest, but expensive )

   3) More than 200 KGS, we will send by sea. ( Cheapest, but long time )



CLUNT market

2014 double row angular contact with bearing 3316 C3 with brass cage2014 double row angular contact with bearing 3316 C3 with brass cage



FAQ

1.Why I choose you?

Profession and reliability. Everyone likes to blow big bubbles. But we need to be honest with ourselves. We maybe not the most handsome, but we have a heart like fire. To meet the morning sunshine, to enjoy our work every day. Say what we mean and mean what we said is our words to ourselves. We work for our family.

2.How long are their lifetime?

  My friend, with your gentle care,6 months to 36 months for different products.

3.How to deal with the quality problem?

Congratulation! You must be winning lottery!

You will get helps by beautiful ladies from our QC terms. There will be discount, secret gifts, of course the new bearings waiting for you.On the other hand, we have a PPAP of each shipment, so that we knowWhich shipment is bad? We will cut off production line and avoid more loss.

4.Can you take responsibility for me?

Of course, I’m happy to help you! But I just take responsibility for my products. We are not willing to see the quality issues, but if happen this problem we will deal with them according to the actual situation.

  1. Please offer a test report.
  2. If it was our fault, absolutely we can make a compensation for you, my friend!
