Help CenterFruit Juice/water/beverage/ Filling and Sealing Production Line Machine
Related Products
-
Customized ISO9001 Hot Juice Bottling MachineUS$ 10,000 - 50,000MOQ: 1 Set -
Automatic 3 in 1 Juice Filling Machine/packing MachineUS$ 10,000 - 30,000MOQ: 1 Unit
-
Complete Fruit Juice Production LineUS$ 10,000 - 50,000MOQ: 1 Unit
-
3 in 1 Juice Filling Equipment / Fresh Orange Juice Filling MachineUS$ 10,000 - 30,000MOQ: 1 Unit
-
Juice Pet Bottle Fill -Capping MachineUS$ 15,000 - 40,000MOQ: 1 Unit
fruit juice filling line parameter
Model |
RCGF12126 |
RCGF18186 |
RCGF24248 |
RCGF32328 |
RCGF404010 |
RCGF505012 |
RCGF606015 |
RCGF808020 |
Number of washing ,filling, capping heads |
12-12-5 |
18-18-6 |
24-24-8 |
32-32-8 |
40-40-10 |
50-50-12 |
60-60-15 |
80-80-20 |
Production capacity |
3000-4000 |
5000-6000 |
8000-10000 |
12000-14000 |
16000-18000 |
20000-24000 |
24000-28000 |
36000-40000 |
|
Suitable bottle type (mm) |
H=170-320 φ=50-100(330-1500ml) |
|||||||
|
Spraying pressure (MPa) |
0.25-0.3 |
|||||||
Total power(kw) |
2.2+0.37 |
2.2+0.37 |
3+0.45 |
5.5 |
7.5 |
11 |
15 |
19 |
Overall dimensions(mm) |
2400×1750 |
2500×1860 |
3100×2100 |
3800×3000 |
4650×3300 |
4850×3650 |
6500×5400 |
7650×6400 |
Weight(kg) |
2600 |
3500 |
4650 |
6800 |
8500 |
10000 |
12500 |
|
juice filling line, hot filling machine
it is used for filling fruit juice, tea drink into PET bottles. we can supply the whole production line.
Characteristics:
1. The washing, filling and capping 3 kinds of jobswill be finished just by this one machine.
2. it is very convenient to change diverse sizes of bottles by means of advanced bottleneck clamping & bottle suspending technology.
3. Advanced programmable PLC is equipped to control the main machine. Working speed can be adjustedby frequency conversion device.
4. In case of overheat it will alarm while if temperature is lower than standard the machine will stop and the liquid will flowback.
5. Main electronic components are all from famous international enterprises.
