Hot Sales Fresh Juice Filling Equipment Price

Hot Sales Fresh Juice Filling Equipment Price thumbnail-1
Hot Sales Fresh Juice Filling Equipment Price thumbnail-2
Hot Sales Fresh Juice Filling Equipment Price thumbnail-3
Hot Sales Fresh Juice Filling Equipment Price thumbnail-4
Hot Sales Fresh Juice Filling Equipment Price photo-1
Hot Sales Fresh Juice Filling Equipment Price photo-2
Hot Sales Fresh Juice Filling Equipment Price photo-3
Hot Sales Fresh Juice Filling Equipment Price photo-4
US$ 2,000 - 15,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Other, Beverage, Carbonated Drink
Packaging Type:
Bottles
Contact Supplier Request Quote Chat Now
Zhangjiagang Jiazhou Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai for fresh juice filling equipment
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Beverage, Other, Beverage, Carbonated Drink
Packaging Type Bottles
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 220V
Power 2.2KW
Place of Origin Jiangsu, China
Brand Name JZ
Model Number RCGF
Dimension(L*W*H) 2850*2750*2950mm
Weight 2T
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas

P/roduct information Zhangjiagang Jiazhou Machinery Co., Ltd.

Product description Hot sales fresh juice filling equipment price

1) The Automatic Fruit Juice Filling Machine is used in production of non-soda drink of fruit juice, fruit wine, minerals and pure water packed in polyester bottles. Washing, filling and capping are integrated in one machine.



2) The most advanced technology from Japan and Germany in the design of the Automatic Fruit Juice Filling Machine. The gravity fixed liquid surface filling is used. The filling is fast, the amount of liquid is accurately controlled and the dropping and leakage are avoided.



3) Spring cramps of the Automatic Fruit Juice Filling Machine are used in the bottle washing process. The empty bottles can be turned over 180~ along the conveying rail. There are two times of internal and external washing, the efficiency of bottle washing is high.



4) The magnetic torque is used for screw capping. The power of screw capping can be adjusted without steps. The power of the screw capping can also be fixed, and the caps will not be damaged, the capping is reliable.



5) The whole Automatic Fruit Juice Filling Machine is controlled by PLC with touch-screen as the human-machine interface. The amount of the drinks in the storage tank can be controlled automatically. The filling and capping will be stopped automatically when there is no bottle. When bottles are cramped wrongly or when caps are not available, the Automatic Fruit Juice Bottling Machine can be stopped automatically.

Product display Hot sales fresh juice filling equipment price

Hot sales fresh juice filling equipment price



Hot sales fresh juice filling equipment price



Hot sales fresh juice filling equipment price

Product Parameters Hot sales fresh juice filling equipment price
Model RCGF
18186		 RCGF
24248		 RCGF
323212		 RCGF
404015		 RCGF
505018		 RCGF
606020
Head of washing, filling, sealing 18-18-6 24-24-8 32-32-8 40-40-10 50-50-18 60-60-20
Production capacity (bottle/hour)   3000-4000 5000-6000 7000-8000 9000-10000 11000-12000 15000
Suitable bottle diameter(mm) φ=50-100 H=150-310 330-1500ml φ=50-100 H=150-310 330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100  H=150-310  330-1500ml
Filling precision ≤±5mm ≤±5mm ≤±5mm ≤±5mm ≤±5mm ≤±5mm
Motor power 3.84kw 4.1kw 5.6kw 7.5kw 9kw 11kw
Filling pressure ≤0.4 ≤0.4 ≤0.4 ≤0.4 ≤0.4 ≤0.4
Overall dimension     (mm) 2400×1900
×2300		 2800×2100
×2300		 4200×2300
×2300		 5000×2800
×2400		 5900×3100
×2400		 6500×3500
×2400
Weight(Kg) 3000 4000 5000 7500 9000 11000
