10KN Two Sheave Steel Hoisting Pulley Block for 6mm Wire Rope

Name: 10KN Two Sheave Steel Hoisting Pulley Block for 6mm Wire Rope
Brand: XINYA
SKU: 140800124

US$ 14 - 20 MOQ: 5 Pieces

Key Specifications

Type:

Other, Other, Steel Hoisting Pulley Block

Material:

Other, Steel, Aluminum Alloy

Place of Origin:

Jiangsu, China

Changshu Xinya Machinery Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Type Other, Other, Steel Hoisting Pulley Block

Material Other, Steel, Aluminum Alloy

Place of Origin Jiangsu, China

Brand Name XINYA

Model Number SHC

10KN Two Sheave Steel Hoisting Pulley Block for 6mm wire rope

Application

Rope Lifting Pulley On Hot Selling/Sheave Block is for lifting.It can be used in single, also can be used as a block.

Characteristics

1.Material: Aluminum alloy

2.Single wheel opening hook type.Two or three sheaves are closed.

3.It is light weight using the aluminum alloy.

Technical Data

Product No.	Model Type	Rated Load(KN)	Sheave	Applicable Steel cable diameter(mm)	Weight(kg)
80399	LZH5-1K	5	1	5.7	1.2
80400	LZH10-1K	10	1	7.7	1.5
80401	LZH10-2	10	2	5.7	1.75
80402	LZH10-3	10	3	5.7	2
80403	LZH15-2	15	2	7.7	2
80404	LZH15-3	15	3	12.5	2.75
80405	LZH20-1K	20	1	11	2
80406	LZH20-2	20	2	7.7	2.5
80407	LZH20-3	20	3	7.7	2.75
80408	LZH30-1K	30	1	12.5	3.5
80409	LZH30-2	30	2	11	4
80410	LZH30-3	30	3	7.7	4.2
80411	LZH50-1K	50	1	15.5	4
80412	LZH50-2	50	2	12.5	4.5
80413	LZH50-3	50	3	11	4.75
80414	LZH80-1K	80	1	18.5	6
80415	LZH80-2	80	2	15.5	6.5
80416	LZH80-3	80	3	15.5	6.75
