Help CenterSubmersible Bore Pump
Related Products
Specifications
Submersible Bore Pump,for water supply from wells or reserviors.Submersible Bore Pump Specification:
Operating conditions:
-Liquid temperature up to 35oC
-Submersion depth 40m
-Minimum internal diameter of well: 102mm.
-Continuous duty.
Motor:
-Tow-pole induction motor (n=2850r.p.m)
-Built-in over load motor protector
-Insulation Class B/F
-Protection IP68
Material:
-External pump body: Stainless Steel
-Suction strainer: Stainless Steel
-Impeller and diffusors: Noryl
-Bearing brackets: Brass
-Shaft: Stainless Steel
-Motor housing: Stainless Steel
-Mechanical seal: Ceramic/Graphite
Application:
-Multistage submersible water pumps with radial closed impeller conceived in order to solve any problem of clean water conveyance.
-Suitable for irrigation, and pressure systems and pressure systems and generally for civil and industrial purposes
