Extruding and Flat Yarn Stretching Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Guanghua
Model Number:
SJ150-K2200
Payment & Shipping
Payment Methods:
Port of Shipment:
AS DISCUSSED
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Automatic Flexografic Printing MachineNegotiableMOQ: 1 Set -
PE/PP FilmExtruding And Laminating MachineNegotiableMOQ: 1 Set
-
Plastic Yarn Granule Making MachineNegotiableMOQ: 1 Set
-
Woven Fabric and BOPP Laminating MachineNegotiableMOQ: 1 Set
-
Plastic Woven Bag Circular Loom MachineryNegotiableMOQ: 1
Place of Origin
Guangdong, China
Brand Name
Guanghua
Model Number
SJ150-K2200
SJ150-K2200 tape stretching machine is operated and controlled on PLC and HMI touch
screen. It consists of SJ150 plastic extruder, melt pump, thickness guage, cool
water tank, film take-off and slitter, puller, heated air oven, stretching &
forming godets, waste tape air sucker and winders. The machine is impacted design
and well structured to keep hi-speed running in stability, easy for operation.
The mentioned configuration mostly improves the quality of product, and saves power,
labor, area and cost, so as to enhance the competitive ability i the market.
It is a priority equipment for plastic pate manufacture.
Features:
1) Even thickness on product
2) Good plastication on product
3) Improve product quality, cut down cost
4) It is the ideal machine to make hi-class and mid-class products
screen. It consists of SJ150 plastic extruder, melt pump, thickness guage, cool
water tank, film take-off and slitter, puller, heated air oven, stretching &
forming godets, waste tape air sucker and winders. The machine is impacted design
and well structured to keep hi-speed running in stability, easy for operation.
The mentioned configuration mostly improves the quality of product, and saves power,
labor, area and cost, so as to enhance the competitive ability i the market.
It is a priority equipment for plastic pate manufacture.
Features:
1) Even thickness on product
2) Good plastication on product
3) Improve product quality, cut down cost
4) It is the ideal machine to make hi-class and mid-class products
SPECIFICATIONS | |
Max. extrusion output |
PE-450kg/h PP-650kg/h |
Total power consumption |
About 600kw |
Screw diameter/L/D |
150(mm)/33:1 |
"T" die length |
2200mm |
Film useful width, center slitting width |
2100mmm, 1050mm |
Max. produce speed |
280m/min |
Elongation index |
4-8 |
Tape tex |
60~200 tex |
