KHYD155 Rock Electric Drilling Rig for Coal Mines

Name: KHYD155 Rock Electric Drilling Rig for Coal Mines
Brand: HuaxiaMaster
SKU: 159062883

US$ 4000 - 4200 MOQ: 1 Set

Key Specifications

Brand Name:

HuaxiaMaster

Place of Origin:

China

Model Number:

KHYD155

Shandong Master Machinery Co., LTD

Payment & Shipping

Payment Methods:

Port of Shipment:

QingDao

Delivery Detail:

Delivery time depends on order quantity.

Brand Name HuaxiaMaster

Place of Origin China

Model Number KHYD155

Type Core Drilling Rig

Certification ISO 9001

After-sales Service Provided Engineers available to service machinery overseas

Warranty 5 years

Weight 7.5kg

Dimension(L*W*H) 3400*1450*2000(mm)

Power Type Electric

Voltage 380/660v

Usage Coal

Condition New

Power(W) 7.5kw

1.The brief introduction of KHYD155 rock electric drilling rig for coal mine

KHYD155 rock electric drill is a tool for rock blasting hole.

a.Drilling rigs should be equipped with drilling rigs, and can be drilled horizontally or inclined upward in any direction.

b.In order to prolong the service life of drill bits and improve the working conditions of operators, water draining powder is called wet drilling.

c.In the operation of drilling rig, we only need to operate the hand wheel, and the drilling machine can push itself forward and return quickly.

2.The technical parameter of KHYD155 rock drills for coal mines

Model	KHYD155
Rated output power of motor (kw)	7.5
Rated voltage of motor (v)	380/660
Rated frequency of motor (hz)	50
Rated current of motor (a)	15.4
Motor speed (r/min)	1440
Motor phase number	Three phase communication
Rated working mode	continuity
Drilling speed (mm/min)	280
Borehole diameter (mm)	42-80（Rock stratum） 80-120（coal seam）
Drilling rigs can be applied to rock hardness range (Prof hardness coefficient)	f
Drilling depth (m) of the maximum rock layer of drilling rig	25
Drilling depth of the maximum coal seam of a drilling rig (m)	40-100
Drill weight (kg)	155
Use cable specifications (user's own) (GB1170-74《Soft cable for mining rubber》)	U type 3x4+1x4
