Aluminum Windows and Doors Making Machine
Functions
The machine is suitable for corner combining of framework and leaf of various aluminum windows, especially heat insulation aluminum window and high grade aluminum alloy door and window. Machine Features: Stable corner combining dues to hydraulic power drive. Left and right punching heads adopt new mechanical linkage device, which realizes completely synchronous corner combining, avoids useless deform and makes the connecting firmly. Less processing error, easier operation and better processing quality. Screw adjusts combining tool s distance, making the tool-setting convenient. Multi-position combining tool is available to process thermal bridge aluminium.
Technique Parameter
Air pressure: 0.5-0.8MPa
Air consumption: 2L/min
Input voltage: 380V 50HZ
Oil pressure: 15MPa
Total power: 1.5KW
Gap error: 0.15mm
Profile width: 100mm
Other Related Machines
Remarks
1. Pkg: Each PC In Wooden Cases
2.Terms: Freight On Board (FOB, Qingdao Port)
3.From Qingdao, China To_______,
4.Delivery Time: During 30 Days After We Receive Your First Payment
5.Payment: Telex Transfer (T/T), 30% Be Paid After Confirming The Order and the rest 70% is effected while delivering the goods
6. Our Trademark: SUNNY
