Mobile High Efficient Compact Gold Wash Plant
1.Features:
1. Compact,mobile concentrator, easy to move and operate;
2. This machine is the most advanced and efficient small scale mining equipment ;
3. great recovery rate down to ultra-fine particles ;
4. Can do continuous process, advanced spiral system, increase gold recovery rate, reduce operator;
5. Portable, simple structure, easy operation, low operating cost.
Integrated Feed Conveyor & Feed Material
• Hopper capacity is 0.2m3 (7 cubic feet) and is fitted with a detachable, horizontal Grizzly to remove +75mm (+3'') material.
• Feed Rate is fully controllable by a combination of Variable Speed Drive to adjust conveyor speed and bolt-on choke plate to allow for complete flexibility of material sizing.
• Hopper can be fed manually or using a mini-excavator.
Drive system
• Concentrator Belt and Trommel drive system: 1.5kW (2.0 HP) 3-phase Drive Motor with Reduction Gearbox.
• Integrated Feed Conveyor drive system: 0.4kW (0.5 HP) 3-phase Drive Motor with Reduction Gearbox.
• Each motor is controlled by a Digital Variable Frequency Controller housed within a waterproof enclosure. Note: Single-phase power supplied to the HPC-15 is supplied directly to the Variable Frequency Controllers which convert the power to 3-phase power required by the Drive Motors. The first Variable Frequency Controllers can be adjusted to set the speed of the Concentrator Belt and Scrubbing / Screening Trommel and the second Controller and be adjusted to set the Feed Rate of the Feed Conveyor.
Feed material:
Maximum: 6” (150 mm) minus material. Recommended: 3” (75mm) minus.
Trommel
Scrubbing & Screening Trommel is 2.8m long with 0.4m diameter and 1.65 m 2-stage Scrubber. Screen is 8mm.
Dimensions:
Length 5.63m, Width 1.76m, Height 1.80m, Weight: 1,700 kg
Trailer:
Single-axle trailer with Pintle-hitch (40mm /1.6’’ ID) - Ball Hitch available - to be specified on order.
Manning:
1 equipment operator required.
Note: for safety reasons, it is always best to have at least 2 people present when operating machinery.
Simple Packaging gold wash plant& Trommel screen .
Packaging the trommel screen spare parts like screen siece by wooden boxes protect damage and loss during transportation ;
Delivery machine by 20-foot & 40-foot container according to trommel gold wash plant total size ;
Be responsible contact with shipping agent arrange machine shipping ,client can also contact shipping agent by himself to delivery our gold wash plant ;
Usually,less than USD30000,T/T100% to reduce bank charge before producing.
More than USD30000,T/T30%as deposit, T/T70% before shipping.
We take pictures of the finished products and send them to the clients before delivery.
If there have any needs,pls feel free to contact us.
