Hydraulic Flaker - soybean oil pretreatment
Soybean oil pretreatment workshop-soybean oil pretreatment
1) Weighing: Soybean is firstly stored in buffer tank which is for adjusting the soybean flow. By means of weighter the processed Soybean is weighted and the imputing quantity is accumulated.
2) leaning and Impurities separating: By means of Vibrating Sieve the larger and smaller size impurities in Soybean are removed out.
3) Gravity De-stoner & Magnetic Separating: some impurities which are as almost same size as Soybean are still mixed in Soybean, but as their gravity or nature properties are different, by means of Gravity De-stoner and Magnetic Separator , the heavy stone and ferric impurities are separated out from Soybean.
4) Crushing & De-hulling: In order to increase protein content in Soya Meal, the de-hulling process is very significant. De-hulling system is composed of Cracking by two Crushing Mill which breaks Soybean into small pieces, and twice separating by Aspirators which separates Soy Hull out from Soya Meal.
5) Flaking: Flaking Machine is adopted for flaking Soya Meat into thin Flake, during which Soybean cell tissue is destroyed.
6) Expanding: The Soya Flake is fed into Expander in which heat is produced with the functions of kneading, friction between the spiral shaft and inner wall of the Expander, meanwhile eject in steam to increase Soya Flake temperature.
7) Drying & Cooling: Jetting out from the end of expander, the Soya Cake is very moist and hot , it should be dried at moisture content 9.5% or so, and cooled down to about 60°C by counter-current-wise down in Cooling Dryer, and then the dried Soya Cake is conveyed into Extraction workshop.
Henan Institute Of Grain Machinery Manufacturing Co., Ltd. is established driven by the academy of Henan University of Technology. As a large joint-stock enterprise integrating technology, manufacturer and sales, our company is specializing in the production of grain and oil machinery, agricultural and sideline machinery.
1. we provide professional technical advising to assemble most suitable machines to you according to the features of your raw material
2. we provide 12 months warranty for our machine
3. we can send our engineers to you to install the complete production line and train your staff
4. we have enginer team to make design for you according to your factory building, we can design technical drawing for you for the installation
5. we have large quantity spare parts in stock, whenever you need spare parts, we can deliver it to you by flight whin 15 days
If you are interested in our products, please feel free to contact me!
