Help CenterQMT42VP6FF2000 Fixed Field Sensor
Related Products
-
EZ-ARRAY Receiver BANNER EA5R300PIXMODQUS$ 580 - 650MOQ: 1 Piece -
BANNER Two-Piece Emitter EA5E300QUS$ 580 - 650MOQ: 1 Piece
-
S18UBAQ Proximity Sensor BannerUS$ 150 - 200MOQ: 1 Piece
-
Banner Laser Sensor Q3XTBLD-Q8US$ 320 - 450MOQ: 1 Piece
-
Banner SC22-3E-S Safety Controller EthernetUS$ 600 - 700MOQ: 1 Piece
QMT42 Series: Fixed Field
Range: 2000 mm; Input: 10-30V dc
Output: SPDT (Complementary) PNP
2 m (6.5 ft) cable
49237
Sensing Mode (General) Proximity
Sensing Mode (Detailed) Background Suppression (Fixed)
Housing Style Rectangular
Primary Housing Material Zinc Alloy Die-Cast
Input/Output Discrete
Max Sensing Distance (mm) 2000
Outputs PNP
Power Supply/Supply Voltage 10-30 V dc
Connection 2 m Cable
Quick Disconnect Type No QD
Sensing Beam Infrared LED
Operation Light/Dark Operate
Min Op. Temp. (°C) -20
Max Op. Temp. (°C) 55
Output response time (ms) 1
Special Feature: Intrinsically Safe No
Special Feature: Remote Teach No
Special Feature: Water Detection No
Sensing Beam Wavelength 880
Delay at Power-up (ms) 100
Repeatability (µs) 250
Number of Pins 4
IP Rating IP67
NEMA Rating NEMA 6
Max Op. Relative Humidity [%] 90% @ 50°C
Adjustments N/A
Barrel Diameter (mm) N/A
Indicator LEDs
