CR825 Injector Test Bench Diesel Common Rail
US$ 10,000 - 12,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HAOSHIYUAN
Model Number:
CR825
Type:
Engine Analyzer
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CR300 Common Rail Injector Test Bench Automatically Generate FQ CodeUS$ 3,200 - 3,600MOQ: 3 Units -
220V/380V Power Supply CR300 Common Rail Injector Test BenchUS$ 3,200 - 3,600MOQ: 3 Units
-
CR825 Test Bench to Test Most of the Common Rail Injectors and PumpsUS$ 10,000 - 12,000MOQ: 1 Set
-
CR 815 Full Function Common Rail Injector Test BenchUS$ 6,200 - 8,000MOQ: 1 Piece
-
China Factory Made Common Rail Test Stand Injector Tester Diesel Common RailUS$ 5,000 - 6,900MOQ: 1 Set
Brand Name
HAOSHIYUAN
Model Number
CR825
Type
Engine Analyzer
Certification
CE/ISO9001
Voltage
220V/380V
Power
7.5kw
Warranty
12 Months
Applicable Models
all car
Products Description
BD- CR825 common rail control system by controlling the operation of the common rail test bench to complete the common rail pumps, common rail injector, high-pressure fuel rail test. Wide range of equipment, can be widely measurement Boch, Denso, Delphi, Siemens and other common rail pump and injector, the injector system is equipped with more than 1600 injectors data, in maintenance and inspection can be used as a reference value or reference value, allowing users repair work more convenient.
Technical Specification |
||||||
Power supply |
3 phase 380v 50hz ,optional 3phase 220v 60hz |
Motor power |
22kw |
|||
Motor rotate |
0-4000RPM/MIN |
Control circuit |
DC 12V/24V 350W |
|||
Oil motor HP/Flow |
0.19KW/ |
ECU internal voltage |
0-200V DC(MAX) |
|||
Diesel motor HP/Flow |
0.19kw/13L/MIN |
Temperature control |
Heating/forced cooling |
|||
Oil tank volume |
30L |
Max rail pressure |
180Mpa,240Mpa(optional) |
|||
Diesel tank volume |
52L |
Flowmeter(fuel supplying) |
1-400L/H |
|||
Flowmeter(injection) |
4-550ml/min |
Flowmeter(oil) |
5-600L(H) |
|||
Flowmeter(fuel flow back) |
4-550ml/min |
Weight |
1700kg |
|||
Test bench dimension |
2250x1260x1920mm |
Wooden case |
2350x1500x2100mm |
|||
Details Images
H- CR825 common rail control system components can be flexibly matching, to form different control platforms to meet the functional, cost, size, and many other needs, to achieve the best quality. In addition the device driver parameters can be flexibly adjusted to suit the pump and injector testing special models, ease of maintenance personnel working status Common Rail System judge and maintenance. The system can also be extended, such as centralized management of multiple devices, unified data reporting, especially for common rail device manufacturers batch testing.
CHARACTERISTIC:
1.Test all the manufacturers of common rail injector
2.Test all the manufacturers of piezo injector
3.Test all the manufacturers of common rail pump
4.Test DENSO HP0 pump
5.Test CAT common rail (HEUI) injector
6.Test CAT common rail (HEUI) engine oil pump
7.Test CAT 320D common rail pump (the world’s first successful development)
8.Test EUI/EUP (can adjust the lift but not to change the camshaft)
9.Test VP44 VE VP37 pump
10.Test RED3 RED4 TICS ZEXEL electronic control pump
11.Drive circuit board(solenold valve electric parameters to enhance the voltage
current,time,pull in voltage ,current,time,keep voltage ,current,time,according to the setting of parameters of production factory)
12.Accept the speed sensor ,encode signal,high speed solenoid valve drive signal.Accept the speed sensor ,encoder signal,output 2PWM drive signal, 2 way solenoid valve drive signal,1 high speed solenoid valve drive signal.
Driving signal waveform can be programed.
1.Test all the manufacturers of common rail injector
2.Test all the manufacturers of piezo injector
3.Test all the manufacturers of common rail pump
4.Test DENSO HP0 pump
5.Test CAT common rail (HEUI) injector
6.Test CAT common rail (HEUI) engine oil pump
7.Test CAT 320D common rail pump (the world’s first successful development)
8.Test EUI/EUP (can adjust the lift but not to change the camshaft)
9.Test VP44 VE VP37 pump
10.Test RED3 RED4 TICS ZEXEL electronic control pump
11.Drive circuit board(solenold valve electric parameters to enhance the voltage
current,time,pull in voltage ,current,time,keep voltage ,current,time,according to the setting of parameters of production factory)
12.Accept the speed sensor ,encode signal,high speed solenoid valve drive signal.Accept the speed sensor ,encoder signal,output 2PWM drive signal, 2 way solenoid valve drive signal,1 high speed solenoid valve drive signal.
Driving signal waveform can be programed.
Product packaging
Packaging
The normal package is polywooden
box(Size: L*W*H). If export to
european countries,the wooden box
will be fumigated.If container is too
tigher,we will use pe film for packing
or pack it according to customers
special request
box(Size: L*W*H). If export to
european countries,the wooden box
will be fumigated.If container is too
tigher,we will use pe film for packing
or pack it according to customers
special request
Company Profile
Tai'an haoshiyuan automobile testing equipment company has its own factory, and Italy is a joint venture founded in 1995, the company is located in the beautiful at the foot of Taishan, the existing 5 million yuan in fixed assets, more than 80 employees. Several of the earliest engaged in the frequency conversion speed injection pump test bench of senior engineers, engineers, technicians and computer software and hardware development experts. The introduction of advanced production and processing equipment and a full set of production technology and product design software, Italy has the world's advanced level of a variety of automotive testing and testing equipment.
Why Choose Us
Product production process using microcomputer control and digital display system, advanced production technology, strong technical force, can produce a variety of equipment 2330. Product quality, high technical performance, with micro control and digital display function. Products are sold all over the country, exported to more than and 20 countries and regions in the world.
Our business purpose is: by virtue of strong technical force, advanced equipment and scientific management to produce high quality products.
The company products Three Guarantees, transport agent, life-long service, training and technical personnel, to provide long-term technical advice
Our business purpose is: by virtue of strong technical force, advanced equipment and scientific management to produce high quality products.
The company products Three Guarantees, transport agent, life-long service, training and technical personnel, to provide long-term technical advice
