APPLICATION:
It is widely used in marking, carving measure, research and so on.
laser 50w
SPECIFICATIONS:
Wavelength (nm) |
1064±1 |
Operating mode |
Q-switched: AOM (Acousto-Optic Modulation) |
Single pulse energy (mJ) |
5~10 |
Pulse duration (ns) |
~85 |
Peak power (kW) |
50~100 |
Rep. rate (kHz) |
1~100, adjustable |
Average power (W) |
Average power (W) = Single pulse energy (mJ) * Rep. rate (kHz) |
50~100@10kHz, typical | |
Ave power stability (over 4 hours) |
<3%, <5% |
Warm-up time (minutes) |
<10 |
Beam divergence, full angle (mrad) |
<3.5 |
Beam diameter at the aperture (mm) |
~7.0 |
Beam height from base plate (mm) |
65.0 |
Cooled method |
Water Cooled |
Operating temperature (°C) |
15~35 |
Power supply (220/110VAC) |
PSU-HPL-Q |
Expected lifetime (hours) |
10000 |
Warranty period |
1 year |
Pilot light (optional) |
5mW @650nm |
Changchun New Industries (CNI) founded in 1996, located in Changchun, CHINA, is a leading manufacturer of solid-state and diode laser systems. Our products include green laser, blue laser, yellow laser, red laser, RGB laser, infrared laser, UV laser, single longitudinal mode laser and Q-switched laser systems. CNI lasers are featured with high performance, low cost and excellent laser beam quality, which are specifically designed for OEM, scientific, industrial and instrumentation use. In addition, CNI lasers are ISO-9001, FDA, CE, RoHS and JQA certified.
CNI also provides laser components and accessories, we aim to offer customers complete laser solutions for all solid state lasers, diode lasers, laser marking system with our most convenient and rapid service.
