WFQ Horizontal Type Paper Jumbo Roller Slitter and Rewinder Machine With Circular Knives To 30mm-1300mm

WFQ Horizontal Type Paper Jumbo Roller Slitter and Rewinder Machine With Circular Knives To 30mm-1300mm photo-1
WFQ Horizontal Type Paper Jumbo Roller Slitter and Rewinder Machine With Circular Knives To 30mm-1300mm photo-2
US$ 5,000 - 15,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
XIAOHAI
Place of Origin:
Zhejiang, China
Certification:
ISO9001
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo China
Delivery Detail:
Delivery time depends on order quantity.
Brand Name XIAOHAI
Place of Origin Zhejiang, China
Certification ISO9001
Type Slitting Rewinder
Warranty 1 Year
Weight 1500kg
Dimension(L*W*H) 1990*1920*1450mm
Condition New
Voltage 220V/380V
Computerized Yes

MACHINE NAME: WFQ Horizontal Type Slitting And Rewinding Machine



Usage:
1.The machine is suitable for slitting and rewinding such various roll materials as BOPP, PET, CPP, CPE, PVC, aluminum foil and paper, etc.

2.Compared with LFQ series,WFQ series is with seperate unwinder device which is special for heavy material,such as paper in roll. Also the machine is with meter counter,EPC,clutch,air shafts,photocell etc.



Specification:




Model No. WFQ-700 WFQ-1100 WFQ-1300
Max.Width of Unwinder material 700mm 1100MM 1300mm
Max.diameter of Unwinder Roll Φ600mm Φ600mm Φ600mm
Width of Rewinder Roll 30-700mm 30-1100mm 30-1300mm
Speed of Slitting and Rewinding 5-160m/min 5-160m/min 5-160m/min
Motor Power 2.7kw 3kw 3.5kw
Weight of Machine 1800kg 2000kg 2200kg
Machine Dimension 2100×1800×1200mm 2100×2000×1200mm 2200×2100×1200mm





Remark:
We also have wider width machine,if you want to do wider material,please feel free to let us know,we will provide you details.Thanks.
