Help CenterMUMA012P1T Panasonic 200VAC Ultra Low Inertia AC Servo Controller
Related Products
-
MADHT1507E02 Panasonic Driver Controller Servopack 50W Power RatedUS$ 1 - 1000000MOQ: 1 Unit -
MADHT1507 Panasonic AC Servo Driver Current Detector Signal OutputUS$ 1 - 1000000MOQ: 1 Unit
-
MHMD082G1U Panasonic Industrial Electronic With Incremental EncoderUS$ 1 - 1000000MOQ: 1 Unit
-
MDMA102D1C Panasonic Motor Moudel Servo On Status Control OutputUS$ 1 - 1000000MOQ: 1 Unit
-
MHMA402A1G Panasonic Industrial Moule 30A Motor Servo-On Control InputUS$ 1 - 1000000MOQ: 1 Unit
| Brand: | Panasonnic | Model: | MUMA012P1T |
|---|---|---|---|
| Place Of Origin: | Japan | Type: | AC SERVO MOTOR |
| Voltage - Rated: | 200VAC | RPM: | 3000 RPM |
| High Light: | ewing machine servo motor,electric servo motor | ||
■Adaptive filter
●Makes the notch filter frequency automatically follow the machine resonance frequency.
●Suppression of "Judder" noise of the machine can be expected which is caused by variation of the machines or resonance frequency due to aging.
■2-channel notch filters
●2-channel notch filters are equipped in the driver independent from adaptive filter.
●You can set up both frequency and width for each of 2 filters, and set up frequency in unit of 1Hz.
●Suppression of "Judder" noise of the machine .
■Damping control
●2-channel damping filters are equipped in this driver. You can suppress vibration occurring at both starting and stopping
in low stiffness machine, by manually setting up vibration frequency in 0.1Hz unit.
●You can also switch the vibration frequency set by 2-channel with rotating direction or with an external input to
correspond to the variation of vibration frequency caused by the machine position.
●Easy setup with entry of only frequency and filter value. Improper setup values do not result in unstable operation
A 3-step gain switch is available in addition to the normal gain switch.This chooses appropriate gain tunings at both stopping and running. The 3-step gain switch gives you choices of 3 different tunings for normal running, stopping for faster positioning and at stopping. The right gaining tunings achieve lower vibration and quicker positioning time of your application.
Inertia ratio conversion
You can adjust right inertia ratio by Inertia ratio conversion input (J-SEL) of interface. When you have significant load inertia changes, it can adjust unbalanced speed and position gain turning combination. lt ends up quicker response of your system.
You can use the parameters to arbitrarily allocate the universal 10 inputs and 6 outputs. (Inputs can be selected as either A contacts or B contacts). The Panaterm setup software provides an exclusive screen for a more simplified setup.
Torque limiter switching
These can be used for applications such as simplified pressure, tension control, and sensor-less homing.
