The Economical Spraying Machine Robot GR6160-3200 is Suitable for Spraying Furniture, Large Boxes, Boards and Frame Parts

The Economical Spraying Machine Robot GR6160-3200 is Suitable for Spraying Furniture, Large Boxes, Boards and Frame Parts thumbnail-1
The Economical Spraying Machine Robot GR6160-3200 is Suitable for Spraying Furniture, Large Boxes, Boards and Frame Parts thumbnail-2
The Economical Spraying Machine Robot GR6160-3200 is Suitable for Spraying Furniture, Large Boxes, Boards and Frame Parts thumbnail-3
The Economical Spraying Machine Robot GR6160-3200 is Suitable for Spraying Furniture, Large Boxes, Boards and Frame Parts thumbnail-4
The Economical Spraying Machine Robot GR6160-3200 is Suitable for Spraying Furniture, Large Boxes, Boards and Frame Parts thumbnail-5
The Economical Spraying Machine Robot GR6160-3200 is Suitable for Spraying Furniture, Large Boxes, Boards and Frame Parts photo-1
The Economical Spraying Machine Robot GR6160-3200 is Suitable for Spraying Furniture, Large Boxes, Boards and Frame Parts photo-2
The Economical Spraying Machine Robot GR6160-3200 is Suitable for Spraying Furniture, Large Boxes, Boards and Frame Parts photo-3
The Economical Spraying Machine Robot GR6160-3200 is Suitable for Spraying Furniture, Large Boxes, Boards and Frame Parts photo-4
The Economical Spraying Machine Robot GR6160-3200 is Suitable for Spraying Furniture, Large Boxes, Boards and Frame Parts photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
2001
Annual Export Value:
Above US$100 Million
Contact Supplier Request Quote Chat Now
Ae Robotics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product Description

GR6160-3200Maxium Reach:3240 mm /
Wrist / Max Payload:16 kg

Highlights
An economical painting robot, non-explosion-proof structure design; Orthogonal spherical wrist structure, large load, high stiffness, wide working range; Default painting application software , built-in I/Os, easy integration, simple programming; Especially suitable for painting furniture, large tank, board and frame parts; Non-explosion-proof robot.
Applications
Specially designed for flat workpiece and similar application scenarios: such as wood doors, window frames, pipes, etc;
Also can be used for multi-size regular parts spraying, such as containers.

Industries
Suitable for furniture, logistics and other industries.

Specification
type
GR6160-3200
Axis
6
Payload
16KG
Net Weight
600kgs
arm reach
3240mm
Repeatability
+/-0.15mm
Mounting
Floor
Ambient temperature
0 - 40°C
Safety Level
EN ISO13849 PLd
axes
Working range
Maximum Speed
J1
±180°
140°/sec
J2
+135°/-70°
140°/sec
J3
+175°/-80°
165°/sec
J4
±360°
500°/sec
J5
±120°
350°/sec
J6
±360°
900°/sec
Packing & Delivery
Packing material: shockproof cotton, insulation paper pad, carton, wooden case
Company Profile
AE Robotics Co,. Ltd
AE Robotics Co., Ltd was established in January 2015. We specialize in discrete industrial automation and industrial process automation, and can design, develop, test installation, commission industrial robots and their cells and related accessories, including accessories, equipment transfer, positioning equipment. and control systems. We can provide collaborative robots, industrial robots, robot parts, CNC controllers, robot integration, etc. We expect our professional technical services to provide our clients with the best return on investment.
