Q1313 135mm Big Spindle Bore Pipe Threading Machine With CE Protection

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Business Type:

Manufacturer

Year Established:

2018

Factory Size:

Below 1,000 square meters

Jingjiang Fuji Technology Co., Ltd.

4Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Pipe Threading Machine Q1313 manufactured by WMT

1.Big spindle bore:135mm

2.Double Chuck

3.High precision

（Item）	（Unit）	Q1313	Q1319	Q1322
Max dia.swing over bed	mm	630			670
Max dia.swing over cross slide	mm	350			380
Max.length of work-piece	mm	1500
Width of bed	mm	550
Spindle bore	mm	135	200	225
Power of spindle motor	Kw	11
Spindle speed	r/min	12-642 FWD.18 steps	24-300 FWD.12 steps	24-300 FWD.12 steps
Z axis feed grade/range	mm/r	26/0.07-1.33	26/0.07-1.33	26/0.07-1.33
X axis feed grade/range	mm/r	22/0.02-0.45	22/0.02-0.45	22/0.02-0.45
Carriage rapid traverse speed	mm/min	4000
Cross slide rapid traverse speed	mm/min	2300
Metric thread grade/range	mm	52/1-224	24/1-14	24/1-14
Inch thread grade/range	T.P.I	40/2-28	40/2-28	40/2-28
Module thread grade/range	mm	53/0.5-120	0.5-7.5	0.5-7.5
DP thread grade/range	D.P.	24/1-28	28-2	28-2
Traverse of cross slide	mm	320
Max. Traverse of turret	mm	200
Tailstock quill travel	mm	250
Tailstock quill Dia./taper	mm	Φ100/（MT5#）
Chuck		3-jaw manual	4-jaw manual
Overall dimensions(LWH)	mm	3657×1360×1480	3657×1360×1555	3657×1360×1480
Net weight	T	4.2	4.5	4.8
