Help Centerev Charging Station
Related Products
Rated Power |
7KW |
11KW |
22KW |
User Interface |
LED indicator, Display screen, Current switch button, Time booking button |
||
Cable Routing |
Bottom inlet wiring, Bottom outlet wiring |
||
Dimension |
310*160*90mm |
||
Input Voltage |
1 phase; 200-240v |
3 phase; 380-440v |
3 phase; 380-440v |
Input Frequency |
50/60hz |
||
Output Voltage |
200-240v |
380-440v |
380-440v |
Output Current |
8-32A |
8-16A |
8-32A |
Charging Wire Length |
3/5/8/10M |
||
Over-current protection value |
≥110% |
||
Over-voltage protection value |
265Vac for 1 phase; 460Vac for 3 phase |
||
Under-voltage protection value |
175Vac for 1 phase; 310Vac for 3 phase |
||
Over-temperature protection value |
80℃ |
||
Electric leakage protection value |
30mA, type A / type B opt |
||
Charging model |
Automatic charging, card swipe, time booking, App control |
||
Communication Interface |
4G/Ethernet/WIFI(optional) |
||
Work temperature |
-30℃-50℃ |
||
Work humidity |
-5%-95% non-condensation |
||
Work altitude |
|||
Protection level |
IP54 |
||
Cooling Model |
Natural cooling |
||
MTBF |
50000hours |
