Help CenterLoading Capacity 32kg Industrial Washing Machine
Related Products
industrial Washing Machine Loading Capacity 32kg industrial Washing Machine
Performance characteristics:
(1) Using Chinese machine dialogue, it can independently complete the functions of adding water, heating, washing, adding agent, even cloth and drying.
(2) New heavy structure, strong and durable. All stainless steel structure, high concentricity, copper wire inverter motor, with high speed and stable frequency converter, high release operation more stable and reliable.
(3) The rotation speed is 500-1000 rpm, and the drying rate is more than 70%, which can well meet the requirements of washing and drying.
(4) The molding level of the whole machine is leading in China, effectively reducing the gap between inner and outer rotating cages, and the manufacturing process is exquisite, saving water, electricity and raw materials.
(5) Equipped with cold and hot double water inlet system, convenient and practical.
(6) Liquid raw material distributor and 03 disinfector connection device shall be equipped to facilitate the perfect connection between automatic soap dispenser and 03 disinfector and equipment. Connect 3-inch 180 degree self-developed advanced drain valve with no failure rate.
(7) Bearing and shaft seal shall be of international famous brand with reliable performance and durability.
(8) Intelligent electronic lock is adopted to ensure safety and ensure stable and reliable high-speed operation.
(9) Large caliber loading door, convenient for loading and taking clothes; one-time mold forming, reduce the wear of loading door to clothes.
(10) New coin slot device configuration, inserted large cash box, fashionable and elegant.
(11) Internet of Things settings, all fault maintenance dispatching operation functions of APP remote management equipment, all technical parameter setting operation functions of APP remote management equipment, and financial statistics analysis of APP remote management equipment. The APP remotely manages the payment and recharge function of the device (WeChat, Alipay, etc., supports other payment connection methods), the APP remotely makes laundry and drying reservation, and customizes and monitors the laundry and dryer function humanely.
Features:
1. Rolls are made from 304 stainless steel, shaft using finely drawn steel, stainless steel outer tube, greatly extend the service life of the machine;
2. The case of Ironing machine sides rack uses high-strength high-quality steel plate welded together, so that the equipment to ensure efficient and stable operation at high load operation;
3. Use variable frequency control, the speed can be adjusted depending on the linen;
4. Equipped with automatic belt tensioner mechanism, according to the thickness and other conditions of energy supply and fabric conveyor belt tensioner automatically to the best condition, improve the quality of ironing
5. Feeding cloth was equipped with a safety shield as long as pushing the shutter, the machine will stop immediately to ensure the safety of operating personnel;
6. Modular cabinet design, so that the machine can be easily upgraded Roller quantity according to customer requirements;
7. Big steam roller end with a lubricant filling device can ensure that the main bearing lubrication, with a safety stop switch;
8. Optional accessories: ironing machine feed table and linen table cloth then, can be selected according to different requirements of customers.
Model |
YPI-8030 |
YPII-8030 |
YPIII-8030 |
YPIIII-8030 |
YPIIIII-8030 |
|
Max. ironing width |
mm |
3000 |
3000 |
3000 |
3000 |
3000 |
Ironing speed |
m/min |
0- 12 |
0- 12 |
0-20 |
0-25 |
0-30 |
Top ironing temp. |
℃ |
180 |
158 |
158 |
158 |
158 |
Steam pressure |
mpa |
|
0.4-0.6 |
0.4-0.6 |
0.4-0.6 |
0.4-0.6 |
Steam consumption |
kg/h |
|
160 |
240 |
320 |
400 |
Heating power |
kw |
72 |
|
|
|
|
Motor power |
kw |
1.5 |
1.5 |
2.2 |
2.2 |
3 |
External dimension |
H |
1370 |
1370 |
1370 |
1370 |
1370 |
D |
2150 |
2150 |
3000 |
3850 |
4700 |
|
W |
4240 |
4240 |
4240 |
4240 |
4240 |
|
Machine weight |
kg |
2040 |
2040 |
2900 |
3760 |
4620 |
