Full Plant Mango Juice Machine

Full Plant Mango Juice Machine thumbnail-3

Full Plant Mango Juice Machine thumbnail-4

Full Plant Mango Juice Machine thumbnail-5

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Business Type:

Manufacturer

Year Established:

2013

Factory Size:

3,000-5,000 square meters

Contact Supplier Request Quote Chat Now

Shanghai Genyond Technology Co., Ltd.

3Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Product Description

Feature:
1.This equipment has excellent manufacture, complete collocation, simple operation. It is consist of extracting tank, concentrated pot, storage tank for liquid material, condenser, oil-water separator, filter, delivery pump, vacuum pump and so on. We have steam heating and electric heat, the user can operate it only to engage the steam or electricity .

2. This equipment collect extraction, vacuum concentration, solvent recovery together and it can realize the operation of normal temperature extraction, low temperature extraction, hot circumfluence, low temperature circumfluence, low temperature concentration and essential oil collection etc.

3. The concentration proportion can get above to1.4 and the temperature can be controlled between 48-100°C freely, so it is espically suitable for some high heat-sensitivity material and some material is sensitive to high temperature.

4. This equipment can configure with PLC control system according to user’s demand and control the parameter during the processing to enhance the production efficiency and quality.

Technology and parameter

Model	GYJ-50	GYJ-100	GYJ-200	GYJ-300	GYJ-500
Volume	50	100	200	300	500
Evaporation capacity (kg/h)	20	50	70	100	200
Motor power(KW)	2.7	2.7	2.7	3.5	3.5
Steam consumption(kg/h)	25	60	90	120	250
System vacuum (MPa)	-0.085	-0.085	-0.085	-0.085	-0.085
Pressure of jacket(MPa)	0.09~0.3	0.09~0.3	0.09~0.3	0.09~0.3	0.09~0.3
Compressed air (MPa)	0.5~0.6	0.5~0.6	0.5~0.6	0.5~0.6	0.5~0.6
Evaporation temperature(°C)	50~90	50~90	50~90	50~90	50~90

4. Machine pictures

5. application

our products are suit for making all kings of fruits slice, bake bread, biscuit, snack. They are as below.

6,company introduction

our products are usually used in industrial produce line. and they are worthy to expending. for the past yeas, we made great progress, our products are not only popular with original country, they also hot sales in other countries. like the middle east, Asian, AFRICA areas. we hope our products will promote your produce rate. Thanks

delivery and package

1. plastic inside to protect machine from wet weather.

2. wooden case packing outside to decrease its damage on the way of delivery

3. fixed wire and center fillers also make sure the safety of the machine

1 Delivery time to North of America is 30~35 days.

2 Delivery time to Asia countries&middle east is 5~30 days.

3 Delivery time to Africa countries is 40~50 days.

4 Delivery time to Euro countries is 30~40 days.

Our service

.PAYMENT: 30% as deposit and 70% before shipment.

DELIVERY: 30 days after the order confirmation, the receipt of the down- payment.

INSTALLATION:

1. We will assemble and test the machine before packing, and provide English manual.

2. If customer need, we will send one or two engineers for assembling and training of workers. The buyer shall bear the engineers round-trip tickets fees, basic accommodation and Transportation, the allowance shall be 70usd/day/person.

welcome your inquires and visitation. thanks
