full automatic fig jams processing line for sale
1. Processing Line
Washing – spraying – air drying--Precooked softening--beating---screw pump----vacuum concentration (dispensing excipients)---screw pump---pneumatic filling---cap sealing-----sterilization----packaging
2.main equipments
1). Small floating wash, spray, clean, dry, choosing good fruit machine
Material:SUS304 2B,Stainless steel roller design. Front with spray, floating per hour capacity: 200 ~ 300 kilograms of fresh fruit.
2).Miniature delicate beater
|
Type |
DSM - 1 |
|
Size |
935 x 320 x 1200 mm |
|
Power |
4.5 KW |
|
Capacity |
350 kg/hour |
|
The first phase screen size |
Φ 1.5 mm |
|
The second phase screen size |
Φ 0.6 mm (optional) |
|
Stand structure, single channel to run the program Touching material part is the SUS304 stainless steel |
|
3) muti-functional vacuum concentrating tank
Mainly used for jam, dairy products, sugar and pharmaceutical kind of element and various material with full after mixing, heating sterilization. It is widely used in the the food, beverage, pharmaceutical industry. The material is SUS304 or 316 stainless steel, GMP production standard.
Equipment parameters:
Effective capacity: 200 l,
Plate for 304 # stainless steel;
Circular glass audition, with light.
Bladder polishing for 300 mesh, the appearance of the 2 b inferior smooth;
The scraper agitator to material for vacuum concentration;
Fully enclosed top with 0 ° manhole, and fly dust breather hole, 360 degrees of rotation CIP cleaning head;
Digital thermometer, temperature display range 0 °C - 100 °C;
Equipment for three layer insulation with heating, temperature control structure.
Double top feed port φ 51;
Equipment contains stainless steel operating platform.
GENYOND MACHINERY INDUSTRIAL GROUP
It has 6 factories in China for food machine and packing machine.
Shanghai Genyond Technology Co Ltd; Zhangjiagang Genyond Machinery Co Ltd
Shanghai Jou Yu industrial Co Ltd; Shanghai Keyfood Machinery Co Ltd
Sino topone machinery; Nantong Yihai Machinery; Kunshan Kpack Machinery
Our products have been exported to more than 160 countries with Annual sales reaching 80 millions in 2022 and it raises by yearly average 10% above.
Genyond machine has more than 100 engineers for the installation of oversea projects.
You just need to give us your idea on final product to be made, processing capacity, way of packing, we will make the proposals for your checking. You can also give us your budget, we can also design a line to meet your budget accordingly.
A satisfying project will be given; A long-term cooperation will come.
