Pre-Mix Juice Dispenser

Pre-Mix Juice Dispenser thumbnail-1
Pre-Mix Juice Dispenser thumbnail-2
Pre-Mix Juice Dispenser thumbnail-3
Pre-Mix Juice Dispenser thumbnail-4
Pre-Mix Juice Dispenser thumbnail-5
Pre-Mix Juice Dispenser photo-1
Pre-Mix Juice Dispenser photo-2
Pre-Mix Juice Dispenser photo-3
Pre-Mix Juice Dispenser photo-4
Pre-Mix Juice Dispenser photo-5
US$ 270 - 400 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
ECOOL&Yicoo
Place of Origin:
China
Model Number:
PMS2T
Contact Supplier Request Quote Chat Now
Ecool (Qingdao) Electronic Machinery Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name ECOOL&Yicoo
Place of Origin China
Model Number PMS2T

Refrigeraged Pre-Mix Liquid Dispenser

☆LED surface light source lightbox
☆Quick assembly and disassembly patent sliding track valve design
☆304 stainless steel push rod or pressure rod
☆Thickened micro-porous PU insulation storage room

Main technical parameters

      model

Parameter 		mechanical valve series peristaltic pump series
PMS2T PMS2P PMS3T PMS3P PMP2C Mini-PMP1C
Push rod type pressure rod type push rod type pressure rod type
Number of valve ports 2 3 2 1
Climate type SN
Anti electric shock protection I
Power supply AC220V~,50Hz
Rated current (A) 0.30 0.60 0.30
Rated power (W) 60 80 60
Power consumption (kW. h/24h) 0.55 0.78 0.60
Total effective volume (L) 33 31 25 11
Storage temperature (ºC) 0~8
Refrigerant and filling amount R600a,29g R600a,19g
Foaming agent C-P/I-P
Noise dB (A) 40
Number of valve ports and packaging of raw materials 2×10L 3×7.5L 2×10L 1×10L
External dimensions (mm) width 435 x depth 525 x height 885mm width 300 x depth 525 x height 707mm
Net weight (Kg) 35 36 40 29


Explanation: 1. This power consumption is the standard power consumption when the device is powered on and running normally without cup making operation.
2. There is a possibility of technical upgrades in all products. If there are any changes, please refer to the product nameplate without further notice. We apologize for any inconvenience caused.
3. The length of the BIB material package used in the mechanical valve series products should not be less than 180mm, and the outer diameter should be between 10 and 16mm.
