Pure Titanium And Titanium Alloy Sheet, Strip, Bar, Tube, Extrusion
We offers a complete range of titanium and titanium alloy mill products in sheet, strip, plate, billet, bar, rod, extrusions and tubulars. We also offer metal processing services including hot-forming (e.g super plastic forming), extrusion,seamless pipe production, water jet and saw cutting, and machining.
| Product Name | Titanium |
| Titanium Bars/ Rods/Ingots | Ф3mm~Ф1020mm,the maximum weight is up to 12t |
| Titanium Slab | (80~400)mm×(~1500)mm×(~2600)mm |
| Titanium Forgings | Weight per piece≤2000kg |
| Titanium Hot-rolled plates | (4~100)mm×(800~2600)mm×(2000~12000)mm |
| Titanium Cold-rolled plates | (0.01~4.0)mm×(800~1560)mm×( ~6000) mm |
| Titanium Strips | (0.01~2.0)mm×(800~1560)mm×L |
| Titanium Tubes / Pipes | Ф(3~114)mm×( 0.2~5)mm × (~15000)mm |
| Standards | GB,GJB,ASTM,AMS,BS,DIN,DMS,JIS,ГОСт |
| Titanium Grade |
|
| Titanium | Composition Requirements, weight percent | |||||||||
| Grade | C | O | N | H | Fe | Al | V | Pd | Ni | Mo |
| 1 | ≤0.08 | ≤0.18 | ≤0.03 | ≤0.015 | ≤0.20 | - | - | - | - | - |
| 2 | ≤0.08 | ≤0.25 | ≤0.03 | ≤0.015 | ≤0.30 | - | - | - | - | - |
| 3 | ≤0.08 | ≤0.35 | ≤0.05 | ≤0.015 | ≤0.30 | - | - | - | - | - |
| 4 | ≤0.08 | ≤0.40 | ≤0.05 | ≤0.015 | ≤0.50 | - | - | - | - | - |
| 5 | ≤0.08 | ≤0.20 | ≤0.05 | ≤0.015 | ≤0.40 | 5.5~6.75 | 3.5~4.5 | - | - | - |
| 7 | ≤0.08 | ≤0.25 | ≤0.03 | ≤0.015 | ≤0.30 | - | - | 0.12~0.25 | - | - |
| 9 | ≤0.08 | ≤0.15 | ≤0.03 | ≤0.015 | ≤0.25 | 2.5~3.5 | 2.0~3.0 | - | - | - |
| 11 | ≤0.08 | ≤0.18 | ≤0.03 | ≤0.015 | ≤0.20 | - | - | 0.12~0.25 | - | - |
| 12 | ≤0.08 | ≤0.25 | ≤0.03 | ≤0.015 | ≤0.30 | - | - | - | 0.6~0.9 | 0.2~0.4 |
| 16 | ≤0.08 | ≤0.25 | ≤0.03 | ≤0.015 | ≤0.30 | - | - | 0.04~0.08 | - | - |
| 17 | ≤0.08 | ≤0.18 | ≤0.03 | ≤0.015 | ≤0.20 | - | - | 0.04~0.08 | - | - |
| 23 | ≤0.08 | ≤0.13 | ≤0.03 | ≤0.0125 | ≤0.25 | 5.5-6.5 | 3.5~4.5 | - | - | - |
| Titanium | Tensile Strength | Yield Strength | Elongation | Bend Test(Radius of Mandrel) | |
| Grade | ksi [MPa] | 0.2% offset, ksi [MPa] | in 2", % | t | 1.8 mm≤t |
| 1 | ≤35 [240] | 20~45 [138~310] | 24 | 1.5T | 2T |
| 2 | ≤50 [345] | 40~65 [275~450] | 20 | 2T | 2.5T |
| 3 | ≤65 [450] | 55~80 [380~550] | 18 | 2T | 2.5T |
| 4 | ≤80 [550] | 70~95 [483~655] | 15 | 2.5T | 3T |
| 5 | ≤130 [895] | ≤120 [828] | 10 | 4.5T | 5T |
| 7 | ≤50 [345] | 40~65 [275~450] | 20 | 2T | 2.5T |
| 9 | ≤90 [620] | ≤70 [483] | 15 | 2.5T | 3T |
| 11 | ≤35 [240] | 20~45 [138~310] | 24 | 1.5T | 2T |
| 12 | ≤70 [483] | ≤50 [345] | 18 | 2T | 2.5T |
| 16 | ≤50 [345] | 40~65 [275~450] | 20 | 2T | 2.5T |
| 17 | ≤ 35[240] | 20~45 [138~310] | 24 | 1.5T | 2T |
| 23 | ≤120 [828] | ≤110 [759] | 10 | 4.5T | 5T |
| Category | Material | Dimension(mm) | Specification |
| Ti & Alloy ingots & bars | CP Ti, Ti-6Al-4V, Ti-6Al-4V Eli, Ti-3Al-2.5V, Ti-5Al-2.5Sn, Ti-5Al-2.5Sn Eli, Ti-0.05Pd, Ti-0.2Pd, Ti-6Al-7Nb, Ti-13Nb-13Zr, Ti-0.1Ru, Ti-3Al-8V-6Cr-4Mo-4Zr, Ti-6Al-4V-0.1Ru, etc. |
Standard Or Customized |
GB/T 2965, ASTM B348 |
| Ti & Alloy castings | GB/T 6614, ASTM B367 | ||
| Ti & Alloy forgings | GB/T 25137, ASTM B381 | ||
| Ti & Alloy plates | GB/T 3621, ASTM B265 | ||
| Ti & Alloy strips & foils | GB/T 3622, ASTM B265 | ||
| Cold rolled Ti & Alloy strip coils | GB/T 26723, ASTM B265 | ||
| Ti & Alloy wires | GB/T 3623, ASTM B863 | ||
| Ti & Alloy seamless tubes | GB/T 3624, ASTM B861 | ||
| Ti & Alloy welded tubes | GB/T 26057, ASTM B862 | ||
| PM Ti & Alloy components | GB/T 6887, ASTM B817 |
Frequently Asked Questions
Question: Can samples be sent?
Answer: Of course. We can send the samples to any part of the world. Our samples are free, but the customer needs to bear the shipping cost.
Question: What product information do I need to provide?
Answer: You need to provide the grade, width, thickness and
the tonnage you wish to purchase.
Question: What are the ports of shipment?
Answer: You can choose other ports as per your needs.
Question: Regarding the product prices?
Answer: Due to the periodic changes in raw material prices, the prices will vary over time.
Question: What certifications do your products have?
Answer: We have certifications such as ISO 9001 and EWC.
Question: How long is your delivery time?
Answer: Generally, our delivery time is 7 to 45 days. However, if the demand is extremely high or there are special circumstances, it may be delayed.
Question: Can I visit your factory?
Answer: Of course, we welcome customers from all over the world to visit our factory.
Question: Does the product undergo quality inspection before being loaded?
Answer: Of course, all of our products are subject to strict quality tests before packaging.
Question: How are the products packaged?
Answer: The inner layer is made of waterproof paper, the outer layer is wrapped in iron sheet, and they are fixed with fumigated wooden pallets. This can effectively protect the products from corrosion during long-distance transportation.
Question: What are your working hours? Answer: Generally speaking, our online service hours are from 8:00 to 22:00. After 22:00, we will respond to your inquiries on the next working day.
