Home > Metallurgy, Mineral & Energy > Steel & Products > Stainless Steel > Special Price ASTM N08800 SAE J405-2018 ASTM A240/240m-2018 Incoloy Alloy 800 Tube / Pipe

Special Price ASTM N08800 SAE J405-2018 ASTM A240/240m-2018 Incoloy Alloy 800 Tube / Pipe

Special Price ASTM N08800 SAE J405-2018 ASTM A240/240m-2018 Incoloy Alloy 800 Tube / Pipe thumbnail-2

Special Price ASTM N08800 SAE J405-2018 ASTM A240/240m-2018 Incoloy Alloy 800 Tube / Pipe thumbnail-3

Special Price ASTM N08800 SAE J405-2018 ASTM A240/240m-2018 Incoloy Alloy 800 Tube / Pipe thumbnail-4

Special Price ASTM N08800 SAE J405-2018 ASTM A240/240m-2018 Incoloy Alloy 800 Tube / Pipe thumbnail-5

Special Price ASTM N08800 SAE J405-2018 ASTM A240/240m-2018 Incoloy Alloy 800 Tube / Pipe photo-1

Special Price ASTM N08800 SAE J405-2018 ASTM A240/240m-2018 Incoloy Alloy 800 Tube / Pipe photo-2

Special Price ASTM N08800 SAE J405-2018 ASTM A240/240m-2018 Incoloy Alloy 800 Tube / Pipe photo-3

Special Price ASTM N08800 SAE J405-2018 ASTM A240/240m-2018 Incoloy Alloy 800 Tube / Pipe photo-4

Special Price ASTM N08800 SAE J405-2018 ASTM A240/240m-2018 Incoloy Alloy 800 Tube / Pipe photo-5

US$ 2000 - 4000 MOQ: 1 Ton

Key Specifications

Get Latest Price

Type:

Stainless Steel Coils

Certification:

ISO, ROHS, IBR, AISI, ASTM, GB, EN, DIN, JIS, Other

Shape:

Round

Contact Supplier Request Quote Chat Now

Zhongzheng Stainless Steel Co., Ltd.

2Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

8 days

Product Details
Company Profile
Contact Us

Type Stainless Steel Coils

Certification ISO, ROHS, IBR, AISI, ASTM, GB, EN, DIN, JIS, Other

Shape Round

Grade Other

Technique Other

Surface Treatment Polished

Standard ASTM, AISI, GB, JIS, DIN, EN, Other

Specification OEM

Trademark ZHONGZHENG INTERNATIONAL

Origin China

Basic Info.

Length

200 feet

Material

304 Stainless Steel

Outer Diameter

8 inch

Type

Seamless Pipe

Wall Thickness

Schedule 10

Surface Finish

No.1, No.4, No.8 Mirror Finish, 2b

Keywords

Electropolished Tubes

Thickness

0.5mm - 75mm

Manufacturing Techniques

Normalized & as Rolled

End Types -01

Seamless Stainless Steel Electropolished Tubes

Delivery Condition

Annealed/Pickled, Ep, Electropolished, Cold Drawn

Standard

ASTM A312 A269 A213 A249 ASME SA312 SA269 SA213

Tubes Range

6.00 mm Od to 25.4 mm Od

Outside Diameter

6.00 mm to 60.00 mm

Schedule Thickness Range

Sch 5, Sch10, Sch 40, Sch 80, Sch 80s, Sch 160

End Types -02

Welded Stainless Steel Electropolished Tubing

Heat Treatment

Normalized & Tempered

Customized

Sizes and Specifications Can Be on Request

Transport Package

Wooden Box Package

Specification

complete

Origin

Zhejiang

HS Code

73041130

Production Capacity

300, 000 Tons Per Year

Product Description

INCOLOY alloys belong to the category of super austenitic stainless steels. These alloys have nickel-chromium-iron as the base metals, with additives such as molybdenum, copper, nitrogen and silicon. These alloys are known for their excellent strength at elevated temperatures and good corrosion resistance in a variety of corrosive environments.
INCOLOY alloy 800 is an alloy of nickel, iron and chromium. The alloy is capable of remaining stable and maintaining its austenitic structure even after long time exposures to high temperatures. Other characteristics of the alloy are good strength, and high resistance to oxidizing, reducing and aqueous environments. The standard forms in which this alloy is available are round, flats, forging stock, tube, plate, sheet, wire and strip.
This datasheet will look into the chemical composition, properties and applications of INCOLOY 800.
Chemical Composition
The chemical composition of INCOLOY alloy 800 is given in the following table.ElementContent (%)


Iron, Fe	≥39.5
Nickel, Ni	30-35
Chromium, Cr	19-23
Manganese, Mn	≤1.5
Others	Remainder

Physical Properties
The following table discusses the physical properties of INCOLOY alloy 800.PropertiesMetricImperial


Density	7.94 gm/cm3	0.287 lb/in3

Mechanical Properties
The mechanical properties of INCOLOY alloy 800 are tabulated below.PropertiesMetricImperial


Tensile strength(annealed)	600 MPa	87 ksi
Yield strength(annealed)	275 MPa	39.9 ksi
Elongation at Break	45%	45%

Other Designations
Some of the designations used to denote INCOLOY alloy 800 are listed below:

UNS N08800	AMS 5766	AMS 5871	ASTM B163	ASTM B366
ASTM B407	ASTM B408	ASTM B409	ASTM B514	ASTM B515
ASTM B564	DIN 1.4876

Fabrication

Machinability
Machining characteristics of this INCOLOY alloy 800 are similar to that of iron-based alloys. This alloy tends to work-harden during machining.
Welding
INCOLOY alloy 800 can be welded by common welding techniques, using a matching filler metal.
Forming
This alloy exhibits good ductility and hence can be formed using conventional methods.
Hot working
INCOLOY alloy 800 can be hot worked at temperature ranges of 871-1232°C (1600-2250°F).
Cold Working
Cold working may be done on the alloy using standard tooling.
Annealing
INCOLOY alloy 800 may be annealed after cold working. Annealing should be done at 982°C (1800°F) for 15 min and then the alloy should be air cooled.
Applications
INCOLOY alloy 800 is used in the following applications:
Heat exchangers
Carburising equipment
Heating elements
Sheathing and nuclear steam generator tubing.

Introduction

ZHEJIANG ZHONGZHENG STAINLESS STEE MANUFACTURING CO. LTD. is a professional supplier of stainless steel materials, located in Zhejiang, China with high speed of economic development. We are near shanghai port; the traffic is very convenient.The main stainless steel materials are stainless steel plate, pressure vessel stainless steel plate, high temperature boiler plate, corrosion resistant stainless steel plate, stainless steel seamless pipe, stainless steel industrial pipe, stainless steel welded pipe, stainless steel bar, stainless steel pipe and so on.With the aim of "quality first, timely delivery, good faith cooperation, considerate service and common development", the company has set up a good reputation in the industry for providing high quality stainless steel materials and perfect after-sales service.
