Help CenterStainless Steel Pipe ASTM A312 304/304L 316/316L Welded/Seamless Hot/Cold Rolled Mirror Polish/Capillary Tubes
Related Products
-
Tp321 Cold Drawn Stainless Steel Seamless Tube Sch160sUS$ 1600MOQ: 1 Ton -
632 Stainless Steel Tube High-Temperature Nickel Based AlloyUS$ 998MOQ: 9 Tons
-
Premium Polished Stainless Steel Tube 3-1220mm From ChinaUS$ 1550MOQ: 1 Ton
-
316L, 304, 301 Stainless Steel Tube, Acid & Alkali Resistant, Brushed, Nichrome, Submersible, Alloy TubeUS$ 2500MOQ: 1 Ton
-
Warehouse Supply ASTM 201 202 304 316L 310S Decorative Stainless Steel Pipe/TubeUS$ 2.0MOQ: 500 Kilograms
Ti 6AL-4V ELI, or Grade 23, is the higher purity version of Ti 6Al-4V. It can be made into coils, strands, wires or flat wires. It's the
top choice for any sort of situation where a combination of high strength, light weight, good corrosion resistance and high toughness
are required. It has a superior damage tolerance to other alloys.
These benefits make Grade 23 the ultimate dental and medical titanium grade. It can be used in biomedical applications such as
implantable components due to its biocompatibility, good fatigue strength and low modulus. It can also be used in detailed surgical
procedures.
Ti-6Al-4V ELI has an improved ductility, toughness in air, and saltwater environments. It is also used in a non-aged condition for
maximum toughness.
Chemical Composition
| Grade | N | C | H | Fe | O | Al | V | Pb | Mo | Ni | Ti |
| Gr1 | 0.03 | 0.08 | 0.015 | 0.2 | 0.18 | / | / | / | / | / | Bal |
| Gr2 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | / | / | Bal |
| Gr3 | 0.05 | 0.08 | 0.015 | 0.3 | 0.35 | / | / | / | / | / | Bal |
| Gr4 | 0.05 | 0.08 | 0.015 | 0.5 | 0.4 | / | / | / | / | / | Bal |
| Gr5 | 0.05 | 0.08 | 0.015 | 0.4 | 0.2 | 5.5-6.75 | 3.5-4.5 | / | / | / | Bal |
| Gr7 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | 0.12-0.25 | / | / | Bal |
| Gr9 | 0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 2.5-3.5 | 2.0-3.0 | / | / | / | Bal |
| Gr12 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | 0.2-0.4 | 0.6-0.9 | Bal |
Tensile Requirements
| Grade | Elongation(%) | Tensile Strength (Min) | Yield Strength (Min) | ||
| ksi | Mpa | ksi | Mpa | ||
| Gr1 | 24 | 35 | 240 | 20 | 138 |
| Gr2 | 20 | 50 | 345 | 40 | 275 |
| Gr3 | 18 | 65 | 450 | 55 | 380 |
| Gr4 | 15 | 80 | 550 | 70 | 483 |
| Gr5 | 10 | 130 | 895 | 120 | 828 |
| Gr7 | 20 | 50 | 345 | 40 | 275 |
| Gr9 | 15 | 90 | 620 | 70 | 438 |
| Gr12 | 18 | 70 | 438 | 50 | 345 |
Applications
★Aerospace industry
★Chemical and marine applications
★Electroplating industry
★Medical industry
★Nuclear industry
★Hydro-carbon processing
★Airframe skin
★Desalination
★Chlorate manufacturing
