Help CenterBently Nevada 135489-04 I/O Module – Rear I/O Interface for 3500-series Vibration and Machinery Protection
Related Products
-
Bently Nevada 140734-05 Dynamic Pressure Monitor (3500/72M)US$ 3216.00MOQ: 1 Blade -
Bently Nevada 1900/27 Series Vibration Monitor – Compact, Reliable Protection for General-Purpose Rotating MachineryUS$ 3216.00MOQ: 1 Blade
-
Bently Nevada 136719-01 Earthing I/O Module – Reliable Shield Grounding for 3500 RacksUS$ 2216.00MOQ: 1 Blade
-
Bently Nevada 1900/55 Fan Monitor – Purpose-built Protection and Condition Monitoring for Industrial FansUS$ 3216.00MOQ: 1 Blade
-
Bently Nevada 1900/65A-00-00-01-00-00 General Purpose Equipment Monitor – Compact Machinery Protection for Pumps, Fans, and MotorsUS$ 3216.00MOQ: 1 Blade
Warranty: 365 days (exchange or repair for quality issues)
Lead time: In-stock items ship in ~1 week; no more than one month at the latest
Payment terms: 50% advance payment; full balance prior to delivery
Express options: FedEx, UPS, DHL
Packaging: ESD-safe, shock-protected for sensitive electronics
Rear I/O termination for 3500 monitors: Connects proximity probes, seismic sensors, and discrete signals to the associated front monitor card.
Buffered transducer outputs (typical): Convenient BNC or terminal access to raw vibration signals for portable data collectors or diagnostics.
Shielded, low-noise design: Layout and grounding practices help maintain measurement integrity in electrically noisy cabinets.
Rack-powered via backplane: No separate power wiring; supplied by the 3500 rack and power supply module.
Field-proven reliability: In many cases these I/O modules run for years without intervention, aside from periodic terminal checks.
Option-matched part number: The “-04” build aligns with a specific monitor/sensor option set—ensures the right terminals and conditioning path.
| Brand / Model | Bently Nevada 135489-04 I/O Module |
| System Compatibility | 3500-series rack and matching front monitor card (monitor-dependent) |
| HS Code | 9032.89 (typical classification for automatic regulating/monitoring apparatus) |
| Power Requirements | Powered via 3500 rack backplane; no external power input |
| Signal I/O Types | Monitor-dependent (e.g., proximity probes, seismic sensors); buffered outputs typically provided |
| Communication Interfaces | Interfaces through the 3500 rack; external comm via 3500/22M (if installed) |
| Installation Method | Rear of rack; mates to corresponding front monitor; field wiring to removable terminals |
| Operating Temperature | Typically 0 to +60 °C (follow 3500 rack environmental ratings) |
| Dimensions & Weight | Matches 3500 rear I/O form factor; single module depth/weight consistent with standard 3500 cards |
This module is used wherever the 3500 system is installed for condition monitoring and protection:
Oil & Gas: compressors, turbines, pumps with proximity and seismic sensing
Petrochemical & Chemicals: multi-stage pumps, blowers, mixers
Power Generation: steam/gas turbines, generators, fans
Pulp & Paper, Metals, Mining: critical rotating assets and balance-of-plant machinery
One maintenance engineer told us the buffered outputs “made troubleshooting a 2-hour job instead of a full shift,” since they could clip a portable analyzer directly without disturbing the monitor.
Reliability: Field-proven modules that typically run continuously in harsh cabinets.
Compatibility: Designed for the 3500 ecosystem; matches transducer types and monitor options.
Maintenance efficiency: Buffered outputs simplify diagnostics and reduce downtime.
Total cost control: Drop-in replacement minimizes engineering rework and commissioning time.
Technical support: We can help confirm option code alignment (the “-04” build) before you place an order.
Panel/cabinet: Install in a clean, ventilated 19-inch cabinet. Maintain airflow around the 3500 rack and avoid heat sources.
ESD safety: Use antistatic protection when handling cards; seat the I/O module squarely onto the backplane connector.
Wiring: Use shielded cable for transducers; terminate shields per Bently Nevada practices to avoid ground loops.
Grounding: Bond rack ground to plant earth; keep sensor returns clean and separated from power grounds.
Checks & care: Periodically retorque terminals, inspect for corrosion, and verify buffered output levels match baseline.
Firmware/config: Any configuration updates are done via the front monitor/3500 system tools (e.g., via 3500/22M communications).
CE compliant; UL/cUL recognition typically applicable to 3500 assemblies
RoHS conformity for electronic assemblies (where applicable)
Manufacturer quality systems aligned with ISO standards
Warranty: 365 days
3500/15 Power Supply Module – powers the rack and I/O/monitor cards
3500/22M Communications Gateway – enables system communications
3500/42M Proximitor/Seismic Monitor – commonly paired with proximity probes and seismic sensors
3300 XL proximity probes, seismic (velocity/accelerometer) transducers, and extension cables
If you share your installed monitor type and option codes, we’ll verify the 135489-04 is the correct rear I/O match before shipment. That small check typically prevents commissioning delays.
