Home > Construction & Decoration > Wire Mesh > Stainless Steel Wire Mesh > Guard Against Landslide Netting Spider Spiral Rope Net Slope Protection Mesh Factory Direct Hot Sale
Guard Against Landslide Netting Spider Spiral Rope Net Slope Protection Mesh Factory Direct Hot Sale
US$ 78.00
100 - 999 Rolls
US$ 76.00
1000 - 1999 Rolls
US$ 73.00
≥2000 Rolls
Key Specifications
Get Latest Price
Material:
Galvanized Steel Wire
Type:
Rope Mesh
Technique:
Woven
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Rockfall Netting Slope Protection High Tensile Wire Mesh 65/3/80/3US$ 6.50 - 9.00MOQ: 100 Square Meters -
SNS Slope Protection Rock Fall Netting Grid Mesh Factory Produce Rockfall Barrier Netting Factory Direct ManufacturerUS$ 7.80 - 8.00MOQ: 3000 Square Meters
-
Slope Protection Mesh/ Spider Spiral Rope Net /Active Protection for Blocky Rock Slopes Hot Sale ManufacturerUS$ 73.00 - 78.00MOQ: 100 Rolls
-
Wholesale Rockfall Netting Flexible Slope Protection 65/3 80/3 80/4 80/4.6 / Slope Protection Mesh Factory Customized ProductionUS$ 8.30 - 9.00MOQ: 100 Square Meters
-
4.6mm SNS High-tensile Flexible Zinc-Aluminum Alloy Slope Protection Mesh Rockfall Wire Mesh Netting Factory Direct SupplierUS$ 5.20 - 5.80MOQ: 100 Meters
Technique
Woven
Model Number
SPIDER spiral rope net
Brand Name
LONGEN
Place of Origin
Hebei, China
Delivery Time
22 ~ 30 days
Processing Service
Chain Link Mesh
Weave Style
Chain Link Mesh
Product name
Product name
Strand Diameter
Strand Diameter
Tensile strength steel wire
1770MPa
Hole size
164x270, 180x300mm
Roll Width
3.3mm, 3.5mm
Roll Length
10mm, 20mm, 30mm
Surface treatment
Hot Dipped Galvanized
Package
Roll
Usage
Rockfall Protection Mesh
Product Description
Spider Spiral Rope Mesh -Mountain Rockfall Protection net
The Spider spiral rope net made from high-tensile wire secures loose, blocky rocks, rock spurs, overhangs or unstable rock
formations with highly irregular surface structures.
formations with highly irregular surface structures.
Product specification
Speider system consists of the SPIDER spiral rope net, grid net, anchors, anchor bearing plate , border and suture ropes and net connection elements.
Speider Spiral Rope Net Standard Specification Strand diameter：6.5mmStrands Structure:1 x3 Hole size：164mmx270mm(+/- 5%)Hole Inscribed circle diameter: 250mm (+/- 5%) Roll width：3.5m Roll length：5m，10m，20m Monofilament intensity: Not less than 1770N/㎡ Zinc mass： Not less than 150g/m2 Breaking force：195-220KN/m |
Grid Net Standard Specification： Wire diameter：2.2mm Hole size: 50mmx50mm Roll width：2mRoll length：20m |
Spike plate
Anchor bearing plate: 320mm x 170/180mm
Anchors ROD
Deformed steel bar anchor diameter: 25mm or 28mm
Length:2m -5m
Rope
Border rope diameter: 12mm or 16mm
Seaming rope diameter: 8mm
Anchor bearing plate: 320mm x 170/180mm
Anchors ROD
Deformed steel bar anchor diameter: 25mm or 28mm
Length:2m -5m
Rope
Border rope diameter: 12mm or 16mm
Seaming rope diameter: 8mm
Details Images
Product Application
Speider Spiral Rope Net Features:
Free choice of anchor points.
Free choice of anchor points.
Tensile strength:1770N/mm2.
More than 250g/m2 zinc coated
Fast mounting of the spiral rope net rolls over large areas.
Suitable for reinforcing existing protection measures
Practically invisible when the vegetation is established.
