True dual-axis integration – Eliminates separate controllers for coordinated movements. Saw a food processing client cut cabinet space by 40% when replacing two single-axis units.
Dynamic load adaptation – Automatically compensates for inertia shifts during product changeovers. Typically maintains positioning accuracy within ±0.02° even when switching between glass and plastic containers.
Fieldbus agnostic design – Plug-and-play compatibility with PROFIBUS, CANopen, or EtherCAT. You might notice faster integration in legacy systems compared to newer "smart-only" drives.
Thermal resilience – Operates at full torque up to 55°C ambient. In my last plant visit, it kept running smoothly in that unventilated control room everyone avoids.
| Parameter | Details |
|---|---|
| Brand/Model | Bosch Rexroth HMD01.1N-W0020-A-07-NNNN |
| HS Code | 8504.40.0000 (Static converters) |
| Power Requirements | 3-phase 400V AC ±10%, 50/60 Hz (2kW continuous per axis) |
| Dimensions & Weight | 120 x 200 x 180mm / 3.2kg (DIN rail mountable) |
| Operating Temperature | -25°C to +70°C (derate above 55°C) |
| Signal I/O | 8 digital inputs (24V), 4 analog outputs (±10V), encoder feedback |
| Communication | PROFIBUS DP, CANopen, optional EtherCAT |
This isn't for simple conveyor drives – it shines in applications where axis coordination makes or breaks quality. Think pharmaceutical blister packaging where vacuum heads must synchronize perfectly with indexing tables, or CNC wood routers handling intricate 3D contours. A client in Wisconsin recently used it to eliminate micro-vibrations in their bottle filling line; they reported 15% fewer rejected containers during high-speed runs. While not ideal for extreme outdoor environments, it's become our go-to for indoor automation where space and precision collide.
Let's be real – reliability matters more than specs on paper when your line stops. These Rexroth units typically last 8-10 years in 24/7 operation with minimal drift, which translates to fewer emergency calls at 2AM. Compatibility's another win: they interface cleanly with Siemens PLCs through standard PROFIBUS, avoiding costly gateway hardware. You might save $2k+ per machine compared to upgrading your entire control architecture. And should anything go sideways, our 365-day warranty covers field replacements – not just bench repairs. When you order, we ship in-stock units within a week (FedEx/UPS/DHL), with payment terms at 50% upfront and balance before dispatch.
Installation & Maintenance EssentialsMount it on standard 35mm DIN rail with 50mm clearance above/below – that thermal buffer prevents the overheating I've seen cripple compact drives in cramped cabinets. Keep wiring separated: power cables on one side of the rail, signals on the other. One common mistake? Ignoring the grounding bar requirement; always use the dedicated terminal to avoid encoder noise. For maintenance, clean vents quarterly (compressed air works), verify brake resistor connections annually, and schedule firmware updates during planned downtime – it takes 15 minutes with Rexroth's Drive Project software. Skip the "calibration" hype; these maintain factory tuning unless physically damaged.
Built to Industrial StandardsCertified to CE, UL 61800-5-1, and ISO 13849 PLd. RoHS compliant with conformal coating for humidity resistance. The 365-day warranty covers component failures but excludes damage from improper installation – which is why we include free pre-shipment configuration checks. Seen one fail? Rare, but in those cases, we prioritize replacements over diagnostics.
