Product Description
1. Application:
Mainly voltage and current protection digital voltage meter with double LED digital display used for household appliance and similar use of low-voltage distribution lines, such as communication, television broadcasting, computer room, automatic control, mechanical equipment, all distribution equipment and lightning protection etc. It is a terminal protecting device of power distribution system of voltage of 500V and below. In low voltage distribution line with rated voltage 230V, rated current 1-63A adjusted, over voltage protection AC240-300V Adjusted, under voltage protection AC140-210V Adjusted and the working frequency is 50Hz. It protects the household appliance as the neutral line potential offset causes by over or under voltage.
2. Features:
A. Small size but high switching capacity.
B. Built-in high performance MCU provides precise voltage protection.
C. Energy-saving, driven by instantaneous impulse coil.
D. Cost-effective, improved circuit design consumes very low power.
E. Flame retardant cover provides good fire, heat and weather resistance.
F. Withstand the impact voltage: 6KV.
G. Outline Modulus Design: Rail mounting. zn, schneider electric, schneider electric in china, voltage protection device, hi voltage protection reley, constant voltage, over under voltage protection, over and under voltage protection 230v, digital voltage protector, thunder protector surge, voltage elemeter, digital electric voltage protector 110v 220v, voltage stablizer coil wind, ac voltage stabilizer din rail, 175, led tv screen protector, voltage stabilizer for tv 55 inch, voge and current protection, protector voltaje 80a, protectores de voltage para nevera, schneider electric price list, protector voltage, solar surge arrestor, voltage protector 110v, relay protection device, voltage protector for refrigerator, fuse relay box, over voltage protection, tv guard voltage protection, schneider, voltage protector, high low voltage protection, fridge guard, dump switch for heater, tv guard, digital ammeter with relay output, digital voltage protector, tv guard voltage protection, surge protection device, voltage stabilizer for led tv, over and under voltage protection 230v, automatic voltage regulator led tv, imanes para refrigerador, lightning protection system, voltaje protector, over voltage and unde voltage protection device, voltage stabilizer, voltage protector for refrigerator, overheating protection voltage stabilizer, protector de voltaje, refrigerator voltage protctor, over under voltage protection, relay controlled power strip, high voltage protector, protector de voltaje 110, tv voltage protector, lipo under voltage protection
3. Electrical Parameters
| Items | Specifications |
| Model | VA-63 1-63A Adjustable |
| Phase | 2P, Up Input Down Output |
| Frequency | 50Hz |
| Rated Current | AC 1-63A adjustable and Default 63A |
| Rated AC Voltage | 230V/ 50Hz |
| Surge Protection Capacity | 175Joules |
| Max. Current/Spike Voltage | 6000A/1.5kV |
| Over-Voltage Action Cut-Off Value | AC240-300V Adjusted and Default 270V |
| Under-Voltage Action Cut-Off Value | AC140-210V Adjusted and Default 170V |
| Power Delay after Power Failure | 5-300s and Default 30s |
| Actiont Time | 0.2-0.3s |
| Power Delay Time in first time | 1-300s and Default 5s |
| Install Way | DIN-rail mounting |
| Warranty | 2 Year |
| Efficiency | 97% |
| Electrical Life | 100K times at least |
| Standard | IEC60898-2 |
| Outline Size | 80x36x66mm |
| Certificate | CE, ISO |
VA-63 1-63A Voltage protector digital voltage meter with double LED digital display adopts the high speed, tiny chip and low power consumption CPU as its’ center processor inside, assembling with magnetic latching relay as its’ main circuit and produced in a high standard of modularized design. The protector can rapidly and safely cut off the circuit to prevent abnormal voltage input the terminal unit and avoid accident occurs when it’s over or under voltage during continuous severe impact of high voltage. The protector will automatically connect circuits within the designed time when the voltage recovery to normal and ensures the terminal equipment runs well under unmanned operation mode. The green indicator LED display lights when the power returns to normal and the red indicator LED display lights when the power is over, under normal voltage range or in delayed conditions. The voltage protector is mounted with 35mm din rail on the equipment unit.
