Tamarind Juice Processing Plant / Tamarind Juice Processing Machine

Tamarind Juice Processing Plant / Tamarind Juice Processing Machine photo-1
Tamarind Juice Processing Plant / Tamarind Juice Processing Machine photo-2
Tamarind Juice Processing Plant / Tamarind Juice Processing Machine photo-3
Tamarind Juice Processing Plant / Tamarind Juice Processing Machine photo-4
Tamarind Juice Processing Plant / Tamarind Juice Processing Machine photo-5
Tamarind Juice Processing Plant / Tamarind Juice Processing Machine photo-6
US$ 70000.00 1 Set
US$ 65000.00 ≥2 Set
Key Specifications
Get Latest Price
video outgoing-inspection:
Provided
machinery test report:
Provided
core components:
Engine, Gearbox, Motor, Gear, Pump
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
video outgoing-inspection Provided
machinery test report Provided
core components Engine, Gearbox, Motor, Gear, Pump
place of origin Shanghai, China
brand name GY
voltage 380
power(w) 2.2kw
weight 5000
dimension(l*w*h) 1380*1200*2000mm
warranty 12 MONTHS
After-sales Service Provided Engineers available to service machinery overseas
Application Kinds
Function Multifunctional
Usage Commercial Usage
Material 304 Stainless Steel
Capacity 500-1000kg/h
Feature High Efficiency Easy Operate
MOQ 1 Set/sets
Advantage High Heat Efficiency
After Warranty Service Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location Germany
Certification ISO9001
Applicable Industries Manufacturing Plant, Food & Beverage Factory, Restaurant, Food Shop, Food & Beverage Shops
Showroom Location None
Marketing Type Ordinary Product
Warranty of core components 2 Years
Condition New



Product Description



Fruit juice production line is composed of water powder mixer, syrup filter,duplex filter,vacuum degasser,UHT sterilizer and homogenizer and so on. The raw material could be fresh fruit or concentrated juice.it canbe used for making all kinds of fruit juice .We also can design custom production lines accordance to customers’ requirements.

 Tamarind Juice Processing Plant / Tamarind Juice Processing MachineTamarind Juice Processing Plant / Tamarind Juice Processing Machine

No.

System

Equipment

Unit

Qty.

1

Water Treatment System

Sand filter

set



Activated carbon filter

set



Water softener

set



Precision filter

set



Reversed osmosis filter

set



Electrical control system

set



Water storage tank

set



2

Fresh Fruit Pre-treatment System

Fruit sorter

set



Fruit washer

set



Fruit Crusher

set



Receive materials tank

set



Juice extractor

set



Enzyme inactivation machine

set



Juice tank

set



3

Ingredients Sterilization system

High-speed emulsion tank

set



Water-Powder Mixer

set



Mixing tank

set



Vacuum Degasser

set



UHT Pasteurizer

set



High pressure Homogenizer

set



4

Filling Packing System



set



5

CIP Cleaning System



set





Tamarind Juice Processing Plant / Tamarind Juice Processing MachineTamarind Juice Processing Plant / Tamarind Juice Processing MachineTamarind Juice Processing Plant / Tamarind Juice Processing MachineTamarind Juice Processing Plant / Tamarind Juice Processing Machine
