As a leading manufacturer at Dongguan Jinchuan Logistics Equipment Co., Ltd., we engineer industrial storage solutions for global operations across North America, Europe, Asia, and beyond. Our Heavy-Duty Radio Shuttle Rack System revolutionizes warehouse efficiency with its exceptional 2000kg per pallet capacity, designed to maximize vertical storage while minimizing aisle space. This robust system delivers tangible ROI through space optimization and reduced handling costs.
Core Technical Specifications:
| Parameter | Specification |
| Structural Frame | Hot-rolled steel columns (90-150mm) |
| Beam Load Capacity | Up to 3,000kg per level |
| Shuttle Car Speed | 0.8-1.2 m/s (adjustable) |
| Battery Operation | 8-10 hours continuous use |
| Positioning Accuracy | ±5mm |
Operational Advantages:
- Space Utilization: Increases storage density by up to 60% compared to traditional racking
- Labor Efficiency: Single operator manages multiple lanes via radio remote
- Safety Integration: Automatic emergency stop and anti-collision sensors
- Adaptive Design: Compatible with both new warehouses and retrofits
Critical Performance Features:
- Dual-motor drive system for consistent heavy-load movement
- Weather-resistant control unit operable in -10°C to 50°C environments
- Modular components enable future system expansion
- Real-time diagnostics through LED status indicators
Trusted by logistics centers across 15+ global markets including Western Europe and North America, our systems undergo rigorous 72-hour continuous load testing before shipment. With manufacturing facilities in Guangdong, we maintain strict tolerance control (±0.5mm on critical joints) ensuring seamless installation worldwide. The corrosion-resistant epoxy coating extends service life in humid environments common across Southeast Asia and coastal regions.
FAQ:
Q1: What's included in the basic system package?
A: Base package includes shuttle cars, rails, rack frames, and one remote controller per 5 cars.
Q2: Can it handle non-standard pallet sizes?
A: Yes, rail width and shuttle dimensions are customizable for 800-1600mm wide pallets.
Q3: What's the required aisle width for forklift access?
A: Minimum 2.8m aisle width for counterbalance forklifts (standard pallet depth).
Q4: How are maintenance services provided internationally?
A: We offer video technical support and ship critical spare parts within 72 hours to major ports.
Q5: What floor load capacity is required?
A: Minimum 5,000kg/m² concrete flooring recommended for full-height configurations.
Q6: Is operator training included?
A: Comprehensive digital operation manuals and 2-hour video training are provided.
