ASME SA210 Seamless Medium Carbon Steel Tube – Superheater Service
Product Overview
ASME SA210 seamless medium carbon steel tubes for superheater and reheater service in power plants. Grade C provides highest strength for high temperature sections.
Grades: A-1 (low temp), C (high temp – most common)
OD: 1/2″ – 5″ | WT: 0.9-12.7mm
✅ Grade C: ≥485 MPa tensile – highest strength carbon steel for superheaters
✅ Up to 900°F (482°C) service
✅ Seamless – no weld seam creep failure risk
✅ 100% hydrostatic + eddy current tested
✅ EN 10204 3.1 MTC with heat number
Superheater Grade Selection
| Grade | Tensile | Max Temp | Application |
|---|---|---|---|
| A-1 | ≥415 MPa | 850°F | Low temperature superheater |
| C | ≥485 MPa | 900°F | High temperature superheater / reheater |
Most Common Superheater Size
| OD | WT | Grade | Application |
|---|---|---|---|
| 2″ (50.8mm) | 4.0-5.5mm | C | High temperature superheater |
Key Requirements
✓ Preheat for welding (Grade C – 150-200°C)
✓ 100% eddy current testing required
✓ Larger bend radius than Grade A-1 (2× OD minimum)
