Stainless Steel 304 Forced Circulation MVR Evaporator, Evaporation Rate 1000kg/h, Low Energy Consumption Design

Stainless Steel 304 Forced Circulation MVR Evaporator, Evaporation Rate 1000kg/h, Low Energy Consumption Design thumbnail-1
Stainless Steel 304 Forced Circulation MVR Evaporator, Evaporation Rate 1000kg/h, Low Energy Consumption Design thumbnail-2
Stainless Steel 304 Forced Circulation MVR Evaporator, Evaporation Rate 1000kg/h, Low Energy Consumption Design thumbnail-3
Stainless Steel 304 Forced Circulation MVR Evaporator, Evaporation Rate 1000kg/h, Low Energy Consumption Design thumbnail-4
Stainless Steel 304 Forced Circulation MVR Evaporator, Evaporation Rate 1000kg/h, Low Energy Consumption Design thumbnail-5
Stainless Steel 304 Forced Circulation MVR Evaporator, Evaporation Rate 1000kg/h, Low Energy Consumption Design photo-1
Stainless Steel 304 Forced Circulation MVR Evaporator, Evaporation Rate 1000kg/h, Low Energy Consumption Design photo-2
Stainless Steel 304 Forced Circulation MVR Evaporator, Evaporation Rate 1000kg/h, Low Energy Consumption Design photo-3
Stainless Steel 304 Forced Circulation MVR Evaporator, Evaporation Rate 1000kg/h, Low Energy Consumption Design photo-4
Stainless Steel 304 Forced Circulation MVR Evaporator, Evaporation Rate 1000kg/h, Low Energy Consumption Design photo-5

Product Spotlights

Forced circulation MVR evaporator with 1000kg/h capacity, made of 304 stainless steel. Low energy consumption (30-50 kWh/ton), PLC automated control, anti-scaling design. Ideal for wastewater, chemical, and food concentration. Backed by ISO-certified manufacturer with global export experience.
US$ 14180 - 329000 MOQ: 1 Combo
Key Specifications
Get Latest Price
Material:
Other, 304 Stainless Steel
Application:
Other, Wastewater treatment
Certification:
Other, ISO9001
Contact Supplier Request Quote Chat Now
Qingdao Conqinphi Environmental Technology Group Co., Ltd.
Gold Verified Supplier
1Yr
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
50 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Other, 304 Stainless Steel
Application Other, Wastewater treatment
Certification Other, ISO9001
Evaporation Rate 1000 kg/h
Type Forced Circulation MVR
Energy Consumption Low (customizable per design)
Control System PLC with touchscreen (optional)
Voltage 380V / 460V / custom
Heating Method Mechanical vapor recompression
Port of Shipment Qingdao, China

As a leading manufacturer since 2015, Qingdao Conqinphi Environmental Technology Group Co., Ltd. is proud to present our Stainless Steel 304 Forced Circulation MVR Evaporator with an evaporation rate of 1000 kg/h. Designed for high efficiency and low energy consumption, this evaporator is ideal for industries requiring reliable concentration and separation of solutions. With our in-house engineering team and a factory spanning over 10,000 square meters, we ensure every unit meets stringent quality standards.

The forced circulation design minimizes scaling and fouling, while the MVR (Mechanical Vapor Recompression) technology reuses vapor heat, drastically reducing operating costs. This model is particularly suited for treating high-salinity wastewater, pharmaceutical intermediates, and food concentrate processes. Our evaporator combines robust 304 stainless steel construction with intelligent automation, providing long service life and easy maintenance.

Key Features

  • High Efficiency MVR System: Compresses secondary steam to reuse latent heat, achieving energy savings of 40–60% compared to traditional multi-effect evaporators.
  • Forced Circulation Design: Prevents crystal deposition and fouling on heat exchange surfaces, ensuring stable operation even with high-viscosity or scaling-prone liquors.
  • 304 Stainless Steel Construction: All wetted parts are made of 304 SS, offering excellent corrosion resistance for food-grade and chemical applications.
  • Fully Automated Control: Equipped with PLC and HMI touchscreen, allowing real-time monitoring of temperature, pressure, flow rate, and concentration.
  • Compact Footprint: Skid-mounted design simplifies installation and reduces on-site piping work.
  • Low Maintenance: Fewer moving parts and a self-cleaning structure minimize downtime.

Technical Specifications

Evaporation Capacity 1000 kg/h (nominal)
Material 304 Stainless Steel (316L optional)
Operating Temperature 60°C – 100°C (adjustable)
Compressor Type Centrifugal / Roots (customizable)
Power Consumption ≈ 30–50 kWh per ton of evaporated water
Control System Siemens PLC + 10″ Touchscreen
Dimensions (L×W×H) 5000×2200×3500 mm (approx.)
Net Weight About 6,500 kg

Customer Benefits

  • Reduced Operational Costs: Lower energy consumption directly cuts electricity and steam bills, with ROI often achieved in 12–18 months.
  • Enhanced Product Quality: Gentle evaporation at low temperature preserves heat-sensitive compounds, perfect for food and pharmaceutical products.
  • Environmental Compliance: Helps meet discharge standards by concentrating waste streams and reducing volume, minimizing disposal fees.
  • Flexible Customization: We offer tailored solutions for specific feed characteristics (pH, viscosity, salinity) and required final concentration.

About Qingdao Conqinphi Environmental Technology Group Co., Ltd. – Since 2015, we have grown into a ISO9001-certified manufacturer with 201–300 skilled employees and an annual export value exceeding US$10 million. Our factory spans 10,000–30,000 m², equipped with advanced welding, machining, and testing facilities. We serve markets across North America, Europe, Southeast Asia, Africa, and Oceania. Each MVR evaporator undergoes rigorous quality checks, including hydrostatic testing, helium leak detection, and performance validation.

Backed by certifications such as ISO9001, ISO14000, OHSAS18001, and others, we are committed to delivering reliable, energy-efficient evaporation solutions. Our experienced technical team provides turnkey support from process design to installation and commissioning. We also offer spare parts and after-sales service via our overseas partners.

Ready to optimize your evaporation process? Contact us today for a detailed proposal and process simulation. With our proven track record and competitive pricing, the Stainless Steel 304 Forced Circulation MVR Evaporator is your best choice for sustainable and profitable concentration.

Frequently Asked Questions (FAQ)

Q1: What types of liquids can this MVR evaporator handle?
A: It is suitable for aqueous solutions with low to moderate viscosity, including wastewater, brine, chemical intermediates, fruit juice, milk, and pharmaceutical extracts. Please provide a sample or composition for optimal design.
Q2: How does forced circulation differ from natural circulation?
A: Forced circulation uses a pump to create high flow velocity across the heat exchanger, preventing scaling and fouling. This is essential for liquids prone to crystallization or high solids content, unlike natural circulation which relies on density differences.
Q3: What is the typical payback period for this evaporator?
A: Depending on local energy prices and operating hours, payback can range from 12 to 24 months. Our team can provide a customized ROI analysis based on your specific conditions.
Q4: Can the evaporator be made of other materials like 316L or duplex stainless steel?

A: Yes, we offer optional materials such as 316L, 904L, and titanium for highly corrosive environments. Please consult our engineers for material selection.
Q5: What is the maximum concentration achievable?
A: The final concentration depends on the feed properties and product requirements. Typically, we can achieve concentrations up to 40–60% by weight, and even higher with specialized designs like crystallizers.
Q6: Do you provide installation and training?
A: Yes, we offer on-site supervision during installation, as well as training for operators and maintenance personnel. Remote support via video calls is also available.
Q7: How long is the warranty period?
A: Standard warranty is 12 months from commissioning or 18 months from shipment, whichever comes first. Extended warranty can be arranged.
Q8: What certifications does your company hold?
A: Our company has passed ISO9001, ISO14000, OHSAS18001, and other management system certifications. Product-specific certifications (e.g., HACCP for food, ATEX for explosive environments) are available upon request.
Product Tags: MVR forced circulation evaporator , 304 stainless steel evaporator 1000kg/h , Low energy consumption MVR system
