Product Name:
FPLP 105°C 300V PVC Fire Alarm Cable
·Flame-retardant Class P
·Self-extinguishing
·Fireproof
Product Application:
Fire cables are mainly used for emergency lighting, fire observation, signal sensing systems, blower systems, communication call systems, control equipment systems, fire pumps, and fire alarm systems.
Circuit cables, etc. For example: school offices, airports, tunnels, railway stations, computers, alarm systems, traffic control systems, fire protection systems, etc.
Product Structure:
Conductor Material: Bare Copper
Conductor Class: Complies with IEC 60228 cl. 1 standard, Complies with IEC 60228 cl.2 standard
Core Insulation: LS-PVC
Drain wire: 1/0.404+0.008mm solid tinned copper (optional)
Shield: Aluminum foil (optional)
Outer sheath: LS-PVC
Sheath color: Red
Test voltage: DC:2500V/2S, no breakdown
Maximum resistance: 5.31 ohms/KM at 20°C
Minimum insulation resistance: 100 MΩ/KFT at 15.6°C
Working voltage: 300V
Temperature rating: -20°C/+105°C
Standard: UL1424
Flame propagation (single insulation): UL2556
Flame propagation (multiple cables): UL1666
Certification standards:
·Standard: UL1424/NEC Article 760
·Compliance: FPLP/CMR/CL3R, Flame test UL1666
·RoHS (European Directive 22/95/EC)
