Henan San Kuang Machinery Technology Co., Ltd., established in 2014 with a factory spanning 10,000–30,000 square meters, is a trusted manufacturer of precision transmission components. Our Gear Spindle Worm Shaft for Textile Machinery Spinning Frame Drive System is engineered for durability and high performance in demanding textile environments. Made from premium alloy steel and processed through advanced heat treatment, this shaft ensures reliable power transmission, reduced vibration, and extended service life. With our 51–100 skilled employees and annual export value of US$2.5–5 million, we deliver components that meet the rigorous standards of global textile manufacturers.
This worm shaft is specifically designed for spinning frame drive systems, where consistent torque and smooth rotation are critical. It combines a precision-ground worm section with a robust spindle profile, enabling efficient gear engagement and minimal backlash. The result is a drive solution that maintains uniform yarn tension, reduces breakage, and enhances overall spinning efficiency.
Key Features & Technical Specifications
- Material Excellence: Manufactured from case-hardening alloy steel (20CrMnTi or equivalent), offering high core toughness and wear-resistant surface.
- Heat Treatment: Carburizing and quenching achieve surface hardness of HRC 58–62, with a hardened depth of 1.0–1.5 mm for long-lasting durability.
- Precision Grinding: Worm profile and bearing journals are ground to ≤0.01 mm tolerance, ensuring smooth meshing and low noise operation.
- Surface Finishing: Available with blackening, phosphating, or zinc plating for corrosion resistance and improved aesthetics.
- Customizable Dimensions: Shaft diameter from 20 mm to 80 mm, length from 100 mm to 2000 mm, with keyways or splines per customer drawings.
- High Load Capacity: Optimized gear tooth design distributes loads evenly, suitable for continuous high-torque applications.
| Parameter | Value |
| Material Grade | 20CrMnTi, 40Cr, 42CrMo (or as required) |
| Hardness | HRC 58–62 (case hardened) |
| Module Range | 2 – 8 (worm module) |
| Lead Angle | 5° – 30° (customizable) |
| Surface Roughness | Ra ≤ 0.8 μm (grinding finish) |
| Balancing Grade | G6.3 or G2.5 (upon request) |
| Certification | Company: ISO9001, ISO14001, OHSAS18001, etc. |
Benefits for Your Production
- Increased Uptime: Superior wear resistance reduces replacement frequency, minimizing maintenance downtime.
- Energy Efficiency: Low friction and precise geometry lower power consumption of the drive motor.
- Consistent Quality: Strict process control ensures repeatable dimensions, batch after batch.
- Global Compatibility: Designed to fit most spinning frame models from leading textile machinery brands.
We understand the critical role of drive components in textile manufacturing. Our dedicated quality team inspects every shaft using coordinate measuring machines and hardness testers. With packaging in sturdy wooden cases or cartons, your orders arrive safely worldwide via Shanghai, Lianyungang, Qingdao, or Tianjin ports.
With over 20 certifications including ISO9001, ISO14001, and SA8000, Henan San Kuang guarantees responsible manufacturing and environmental compliance. Our 51–100 professionals are ready to support your custom requirements, from prototype to mass production. Choose durability—choose San Kuang for your textile machinery drive system needs.
