This is a solenoid-operated, two-way, two-position, normally closed, pilot-operated cone valve with a threaded cartridge design. It is typically used as a shutoff or load-holding device in high-pressure circuits. When the coil is de-energized, the SVG0.S09 functions as a check valve, allowing fluid to flow from 2 to 1 while blocking fluid flow from 1 to 2. When the coil is energized, the cone valve lifts, opening the passage for fluid to flow from Port 1 to Port 2. In this operating mode, fluid flow from Port 2 to Port 1 is strictly restricted. The rigid, one-piece valve body design helps minimize the effects of valve cavity eccentricity, thereby providing high reliability. The optimized flow path design reduces pressure drop.
Performance Features
All external surfaces are zinc-plated for corrosion resistance.
All valve components are manufactured from high-strength steel.
The valve spool is hardened and ground to ensure minimal wear and a long service life.
Coil seals protect the solenoid valve system.
Manual operation is available.
Complies with SAE industry standards.
| Technical Parameter | Specification |
|---|---|
| Origin | Italy |
| Working Pressure | max. 350 bar |
| Flow Rate | max. 40 L/min |
| Response Time (Opening) | 30 ms |
| Response Time (Closing) | 60 ms |
| Internal Leakage | max. 0.25 cm³/min @ 350 bar |
| External Component Treatment | Zinc/Iron - Standard (96 hours) |
| External Component Treatment | Zinc/Nickel (720 hours) - Upon customer request |
| O-Ring Temperature Range | -30°C to 110°C (Standard Seal: Nitrile Rubber, Nitrile Rubber, Nickel) |
| O-Ring Temperature Range | -35°C to 140°C - Hydrogenated Nitrile Rubber - Upon customer request |
| O-Ring Temperature Range | -23°C to 225°C - Fluororubber - Upon customer request |
| Oil Temperature Range | -30°C to 110°C |
| Lubricating Oil | Mineral oil or synthetic oil with lubricant properties |
| Viscosity | 7.4 to 420 cSt |
| Pull-in Voltage | 85% of rated value (min.) |
| Filtration Grade | max. 20 / 18 / 15 ISO 4406 (Allowable filtration grade) |
| Installation Direction | Unlimited |
| Installation Torque | 40 - 45 Nm, Hex 24 |
| Oil Test Conditions | ISO VG 46 cSt |
| Seal Kit | SK.031 and SK.027 (Coil) |
| Coil | 18 W |
| Weight | 0.123 kg |
