Type PV

Product Spotlights

Medium voltage cables for distribution networks, they are suitable for laying indoor, tunnel, cables trench and underground, it is able to bear external mechanical forces, but unable to bear heavy pulling force, it widely used in transformer stations, electric power plants and industrial plants.

Negotiable MOQ: 3000 Meters (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Certification:

ISO9001

Application:

Overhead

Contact Supplier Request Quote Chat Now

Anhui Electric Group Shares Co.,Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

7 days

Product Details
Company Profile
Contact Us

Certification ISO9001

Application Overhead

Application
Solar cables (Type PV) acc. to UL 4703, Single conductors are intended for use in interconnection wiring of grounded and ungrounded photovoltaic power systems. Heat and Moisture Resistant,concealed wiring in wet or dry locations.

Construction
● Conductor : Bare or tinned copper,8000 service aluminum alloy or 1350 aluminum, stranded, circular or circular compressed or circular compacted conductors
● Insulation and Jacket : XL compound,insulated and integrally or non-integrally jacketed

Characteristics
● Rated voltage 600,1000,or 2000V
● Meets cold bend and cold impact tests at -40 °C.
● Max. conductor operation temperature 90°C, 105°C,125°C,or 150°C dry and, 90°C wet
● FV-1 vertical flame rating per UL 2556.
● All aluminum AA-8000 and copper sizes are rated Direct Burial and Sunlight Resistance in all colors.
● Additional/Optional Ratings for all colors are available upon request: VW-1 per UL1581/UL 2556 Gas & Oil Res. I or II per UL 44
● Available in black, white, red, blue, green or other color

Specification
UL 44 Thermoset - Insulated Wires and Cables
UL 4703 Photovoltaic Wire

High reliability

Super high pressure

Less maintenance

Technical Parameter

2000 Volt Aluminum Type PV2000 Volt Copper Type PV

No. of cores and nominal cross section	Min.Number of wires	Conductor diameter	Nominal insulation thickness	Max. DC resistance of conductor at 20℃	Current Carrying Capacity at 90℃
AWG or MCM	No.	mm	mm	Ω/km	A
6	7	4.29	2.159	2.21	55
4	7	5.41	2.159	1.39	75
2	7	6.81	2.159	0.875	100
1	19	7.59	2.667	0.693	115
1/0	19	8.53	2.667	0.550	135
2/0	19	9.55	2.667	0.436	150
3/0	19	10.7	2.667	0.346	175
4/0	19	12.1	2.667	0.274	205
250	37	13.2	3.048	0.232	230
300	37	14.5	3.048	0.194	260
350	37	15.6	3.048	0.166	280
400	37	16.7	3.048	0.145	305
500	37	18.7	3.048	0.116	350
600	61	20.7	3.429	0.0967	385
750	61	23.1	3.429	0.0774	435
1000	61	26.9	3.429	0.0580	500
