Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. As a leading manufacturer established in 2015 with a factory spanning 10,000–30,000 square meters and a team of 201–300 experienced professionals, we are proud to introduce our 3 Ton/H Evaporative Crystallization Unit. This advanced system is engineered with PLC control and constructed from 316L stainless steel, delivering exceptional durability and corrosion resistance. Our unit is designed to achieve low energy consumption while maintaining high efficiency, making it an ideal solution for industries requiring reliable crystallization of liquid streams. With over US$10 million in annual export value and serving markets across North America, South America, Europe, Asia, Africa, and Oceania, we bring global expertise to your facility.
The 3 Ton/H Evaporative Crystallization Unit is a complete system that integrates evaporation and crystallization processes into a single, compact footprint. It is specifically designed for industrial wastewater treatment, chemical processing, and zero liquid discharge (ZLD) applications. The unit utilizes forced circulation evaporation technology combined with a crystallization chamber to separate solids from liquids efficiently. The PLC control system ensures precise automation of temperature, pressure, feed rate, and discharge cycles, minimizing manual intervention and maximizing operational reliability.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Processing Capacity | 3,000 kg/h (3 Ton/H) |
| Material of Construction | 316L Stainless Steel (all wetted parts) |
| Control System | PLC with HMI touch screen, remote monitoring available |
| Energy Consumption | ≤ 60 kWh per ton of water evaporated (low energy design) |
| Operating Temperature | Up to 150°C (customizable) |
| Operating Pressure | Atmospheric or vacuum (optional) |
| Power Supply | 380V / 50Hz (customizable to other voltages) |
| Dimensions (L x W x H) | Customizable per order, typical footprint ~6m x 3m x 4m |
| Weight | Approx. 8,000 kg (dry weight, varies with configuration) |
Product Features & Benefits
- Low Energy Consumption: Our advanced heat pump integration and multi-effect design reduce energy usage by up to 30% compared to conventional evaporators. This translates to significant cost savings on your utility bills.
- 316L Stainless Steel Construction: All components in contact with process fluids are made of 316L SS, offering excellent resistance to corrosion from chlorides, acids, and other aggressive chemicals. This ensures a long service life and minimal maintenance.
- PLC Automation: The system is fully automated with a user-friendly HMI that allows operators to set parameters, monitor real-time data, and receive alarms. The PLC can also be integrated with your existing SCADA system for centralized control.
- High Crystallization Efficiency: The forced circulation loop and optimized crystallizer geometry ensure uniform crystal growth and high solid recovery rates. Typical recovery exceeds 95% for most salts.
- Compact Design: The unit is skid-mounted and pre-piped, reducing installation time and footprint. It can be easily transported and installed on-site with minimal civil works.
- Versatile Applications: Suitable for treating industrial wastewater from chemical, pharmaceutical, food processing, and mining industries, as well as producing high-purity crystals for reuse or disposal.
- Easy Maintenance: The design includes quick-opening doors and easy access to all key components. The 316L surface is smooth and easy to clean, reducing downtime for maintenance.
- Customizable Options: We offer various configurations including vacuum operation, heat recovery, and anti-scaling coatings to match your specific process requirements.
Technical Advantages
The 3 Ton/H Evaporative Crystallization Unit incorporates several engineering innovations:
- Forced Circulation Evaporator: Uses a high-flow pump to circulate the liquid through heat exchangers, preventing fouling and scaling. This ensures stable operation even with high solids concentration.
- Integrated Crystallizer: The draft tube baffle (DTB) crystallizer design promotes large, uniform crystals that are easy to centrifuge and dry.
- Automatic Discharge System: The PLC controls a pneumatic or motorized valve to periodically discharge crystal slurry, maintaining optimum slurry density.
- Vacuum Generation (optional): When equipped with a vacuum pump, the unit can operate at lower temperatures to handle heat-sensitive materials.
- Energy Recovery System: An optional mechanical vapor recompression (MVR) module can further reduce energy consumption to as low as 30 kWh/ton.
Why Choose Qingdao Conqinphi?
As a manufacturer with 10+ years of experience and a dedicated R&D team, we have supplied over 200 crystallization units globally. Our factory is equipped with advanced CNC machining and welding facilities, ensuring high-quality fabrication. We have a professional after-sales team that provides installation guidance, commissioning, and training. Our annual export value exceeds US$10 million, and we serve clients in more than 30 countries. We are committed to delivering reliable, cost-effective solutions that meet your environmental and production goals.
Trust in our quality: Our manufacturing processes are carried out under strict quality management systems, and we offer factory acceptance tests (FAT) and site acceptance tests (SAT) to ensure performance. We also provide one-year warranty and lifetime technical support. Contact us today to discuss your specific requirements and receive a customized proposal.
Frequently Asked Questions (FAQ)
-
Q: What is the typical payback period for this unit?
A: Based on energy savings and reduced disposal costs, many clients achieve payback within 12–18 months. Actual payback depends on local electricity prices and waste disposal fees. -
Q: Can the unit handle high-chloride or acidic wastewater?
A: Yes, the 316L stainless steel construction provides excellent resistance to chlorides and mild acids. For highly corrosive streams, we can also offer Duplex stainless steel or other alloys upon request. -
Q: What is the required floor space for installation?
A: The unit is skid-mounted and typically requires a footprint of approximately 6m x 3m with an additional 2m clearance for maintenance. We can customize the layout to fit your space. -
Q: Do you provide training for operators?
A: Yes, we offer on-site training for your operators as part of the commissioning service. We also provide detailed operation manuals and remote support. -
Q: What is the power supply requirement?
A: The standard unit is designed for 380V/50Hz, 3-phase. We can adapt to other voltage/frequency configurations (e.g., 480V/60Hz) with minor modifications. -
Q: Is the unit suitable for pharmaceutical applications?
A: Absolutely. The 316L stainless steel construction and smooth surfaces meet sanitary standards. We can also provide additional polishing and documentation to support validation. -
Q: How long does delivery take?
A: Typical lead time is 8–12 weeks from order confirmation, depending on customization requirements. We can expedite for urgent orders. -
Q: What is the warranty period?
A: We offer a standard 12-month warranty from the date of commissioning, covering defects in materials and workmanship. Extended warranty options are available.
